Windows procedure
1. Go to the Color Center in the HP Utility. Click Prole Management, then .
2. Select the paper type that you will use with the ICC prole, and select the le containing the ICC prole.
NOTE: ICC prole le names have the extensions ".icc" (for International Color Consortium) or ".icm" (for
Image Color Matching).
3. Check the ICC prole name, then click Next.
4. The ICC prole is installed in your computer and will be available to use in your applications.
Mac OS X procedure
1. Go to Paper Preset Management in the HP Utility and select the color prole to be installed.
2. Click at the bottom of the window, then click Install prole.
Export a color prole
An ICC prole associated with a paper type can be exported, enabling it to be used on a dierent printer or with a
dierent paper preset..
Windows procedure
1. Go to the HP Color Center in the HP Printer Utility. Click Prole Management, then at the bottom of the
page.
2. Select the paper type and the ICC prole to be exported.
3. Choose the pathname of the folder in which the ICC prole will be saved in your computer.
4. The ICC prole le is saved in the specied folder.
Mac OS X procedure
1. Go to Paper Preset Management in the HP Utility and select the paper type and ICC prole to be exported.
2. Click , then Export ICC prole.
3. Choose the pathname of the folder in which the ICC prole will be saved in your computer, and click
Continue.
Restore an original color prole
The ICC prole settings in a paper preset can be restored to their original values. This will remove any ICC prole
that you have associated with the selected paper and restore the default ICC prole provided by HP.
Windows procedure
1. Go to the HP Color Center in the HP Printer Utility. Click Prole Management.
2. Select the paper type whose ICC prole you want to restore. Click Restore.
Mac OS X procedure
1. Go to Paper Preset Management in the HP Utility and select the ICC prole.
2. Click , then Restore factory ICC prole.
78 Chapter 8 Color management ENWW
