Table 6-9 POST error messages (continued)
Screen message Probable cause Recommended action
513—Front Chassis fan not
detected
Front fan missing, disconnected, or
defective.
1. Reseat the fan cable.
2. Reseat the fan.
3. Replace the fan.
514—Memory fan not
detected
Memory fan missing, disconnected, or
defective.
1. Reseat the fan cable.
2. Reseat the fan.
3. Replace the fan.
515—CPU Overtemp
occurred
Insufficient processor cooling or
processor defect.
1. If necessary, add a heatsink to the processor and
ensure proper operation.
2. Replace the processor.
516—Chipset fan not detected Chipset fan missing, disconnected, or
defective.
1. Reseat the fan cable.
2. Reseat the fan.
3. Replace the fan.
517—Low power CPU
heatsink(s) detected for high
power CPUs
Inadequate heatsink is installed. Replace the low power heatsink with a high power
heatsink.
518—Power supply wattage
insufficient for hardware
configuration
Computer configuration requires more
power than the power supply can
provide.
1. Reduce the computer power consumption.
2. Replace the power supply with a high output
power supply.
601—Diskette Controller Error Diskette controller circuitry or diskette
drive circuitry incorrect.
1. Run the Computer Setup (F10) utility.
2. Verify cabling and replace defective cables if
necessary.
3. Clear CMOS.
4. Replace the diskette drive.
5. Replace the system board.
605—Diskette Drive Type
Error
Mismatch in drive type. 1. Run the Computer Setup (F10) Utility.
2. Disconnect any other diskette controller devices
(tape drives).
3. Clear the CMOS.
610—External Storage Device
Failure
External storage device is not
detected, is improperly connected, or
is defective.
1. Verify that the external device is present and
connected properly.
2. Replace the external device.
611—Primary Floppy Port
Address Assignment Conflict
The flexible disk drive is configured at
a previously assigned address.
Select a new address for the flexible disk drive.
912—Computer Cover Has
Been Removed Since Last
System Start Up
N/A No action required.
ENWW
Diagnostic codes and errors
143
