Workstation specifications
This section provides workstation chassis, power supply, and environmental specifications.
Physical characteristics
The following table lists the workstation physical characteristics.
Weight (Typical configuration) 10.4-14.8 kg (22.9-32.5 lb)
Chassis Dimensions Height: 44.8 cm (17.6 in)
Width: 17.8 cm (7.0 in)
Depth: 45.4 cm (17.9 in)
Power supply description
The workstation includes a 400W 90% efficient 80PLUS gold-level power supply, which is compatible
with ENERGY STAR requirements.
Power supply voltages
Table 1-4 Power supply source voltages
Source voltage Description
V12CPU Input to onboard regulator that supplies power to CPU and CPU fan
V12-B Storage (hard disk drive, optical disk drive, diskette drive), PCIe slots,
system fans
V12 S Input to onboard regulators
V12–G Auxilliary power for graphics
V12N PCI and serial port
11VSB Input for sleep circuitry
