Power supply specifications
Table 1-6 Power supply specifications
Item Description
Power supply 400W Wide Ranging, Active PFC and 90% efficient at typical
loads
Operating voltage range 90–269 VAC
Rated voltage range 100–240 VAC
Rated line frequency 50–60 Hz
Operating line frequency range 47–63 Hz
Rated input current 6A @ 100-127 VAC
3A @ 200–240 VAC
Heat dissipation
(Configuration and software dependent)
Typical: 985 btu/hr
Maximum 1569BTU/hr = (395.4 kg-cal/hr)
Power supply fan One fan, 92mm x 25mm, variable speed
ENERGY STAR Qualified (Config dependent) Yes
80 PLUS® Compliant Yes, Gold-level rating
FEMP Standby Power compliant @115V (<2W in
S5 – Power Off)
Yes
ERP Lot 6 Tier 1 Compliant@ 230V (<1W in S5
– Power Off)
Yes
ERP Lot 6 Tier 2 Compliant @ 230V (<0.5W in
S5 – Power Off)
Yes
Built-in Self Test LED Yes
Surge tolerant full ranging power supply
(withstands power surges up to 2000V)
Yes
Power Consumption in sleep mode (as defined
by ENERGY STAR) - Suspend to RAM (S3)
(Instantly Available PC)
<4W
Power consumption and heat dissipation
Power consumption and heat dissipation specifications are available for multiple configurations. To
review available specifications, see
http://www.hp.com/go/quickspecs.
To reach zero power consumption, unplug the workstation from the power outlet or use a power strip
with an on/off switch. For additional information about power-saving features, see the operating system
installation instructions.
This product is in compliance with U.S. Executive Order 13221.
