Inserting a PC Card
CAUTION: To prevent damage to the computer and external media cards, do not insert an
ExpressCard into a PC Card slot.
CAUTION: To reduce the risk of damage to the connectors:
Use minimal force when inserting a PC Card.
Do not move or transport the computer when a PC Card is in use.
The PC Card slot may contain a protective insert. The insert
must
be
removed before you can insert a
PC Card:
1. Pres
s the PC Card eject button (1).
This action extends the button into position for releasing the insert.
2. Press the PC Card eject button again to release the insert.
3. Pull the insert out of the slot (2).
To insert a PC Card:
1. Hold the card label-side up, with the connectors facing the computer.
2. Insert the card into the PC Card slot, and then press in on the card until it is firmly seated.
You will hear a sound when the card has been detected, and a menu of available options may
be displayed.
NOTE: The first time y
ou connect a PC Card, a message in the notification area lets you know
that the device is recognized by the computer.
36 Chapter 5 External cards and devices
