12. Slide the keyboard back toward the display (1), and then rotate it forward (2) to gain access to the
keyboard cable connector.
NOTE: Refer to the illustration that most closely matches your computer.
CAUTION: Do not rip the keyboard cable.
– or –
Slide the keyboard back toward the display (1), and then rotate it to the right side (2) to gain access
to the keyboard connector.
CAUTION: Do not rip the keyboard cable.
13. If you are replacing a memory module, remove the existing memory module:
CAUTION: To prevent damage to the memory module, hold the memory module by the edges
only. Do not touch the components on the memory module.
a. Pull away the retention clips (1) on each side of the memory module.
The memory module tilts up.
118 Chapter 9 Memory modules
