X Family Hardware Installation Guide V 2.5.1.1 39
Connector and Pinout
Specifications
This appendix provides connector and pinout information for the X5 and X506 systems.
Port Connectors
X5 and X506 Port Connectors
The X5 and X506 support 10/100 RJ-45 connectors, which have pinouts as described in this section.
The following figure displays an RJ-45 connector.
.The following table describes the pinout information for a 10/100 RJ-45 connector.
Figure A - 1: RJ-45 Connector
Table A - 1: RJ-45 10/100 Base-T Connector Pinouts
Pin Number Signal Name
1Transmit positive
2Transmit negative
3 Receive positive
