Workstation Family Quick Reference Guide

6
HP ZBook 15 G3 HP ZBook 17 G3
Overview Portable powerhouse. Ultimate mobile performance.
Operating systems
Windows® 10 Pro 64
12
Windows® 10 Home 64
12
Windows® 7 Professional 64
13
Windows® 7 Professional 64 (available through downgrade rights
from Windows 10 Pro)
13
FreeDOS 2.0
Windows 10 Pro 64
12
Windows 10 Home 64
12
Windows® 7 Professional 64
13
Windows 7 Professional 64 (available through downgrade rights
from Windows 10 Pro)
13
FreeDOS 2.0
Processor/chipset
24
Intel® Xeon® E3-1545M v5 with Intel® Iris™ Pro Graphics P580
2
Intel® Xeon® E3-1505M v5 with Intel® HD Graphics P530
2
Intel® Core™ i7-6820HQ with Intel® HD Graphics 530
2
Intel® Core™ i7-6700HQ with Intel® HD Graphics 530
2
Intel® Core™ i5-6440HQ with Intel® HD Graphics 530
2
Mobile Intel® CM236
Intel® Xeon® E3-1575M v5 with Intel® Iris™ Pro Graphics P580
2
Intel® Xeon® E3-1535M v5
2
with Intel® HD Graphics P530
8
Intel® Core™ i7-6820HQ
2
with Intel® HD Graphics 530
2
Intel® Core™ i7-6700HQ
2
with Intel® HD Graphics 530
2
Intel® Core™ i5-6440HQ
2
with Intel® HD Graphics 530
2
Mobile Intel® CM236
Slots available/maximum memory/
number of memory channels
3
Four SODIMM slots supporting dual channel memory up to 64 GB
DDR4 1.35V ECC or Non-ECC SDRAM (With transfer rates up to
2133MT/s)
4 GB, 8 GB and 16 GB SODIMMs (for Intel® Core™ Processors)
8 GB and 16 GB ECC SODIMMs (for Intel® Xeon® Processors)
Four SODIMM slots supporting dual channel memory up to 64
GB DDR4 1.35V ECC or Non-ECC SDRAM (Transfer rates up to
2133MT/s)
4 GB, 8 GB and 16 GB SODIMMs (for Intel® Core™ Processors)
8 GB and 16 GB ECC SODIMMs (for Intel® Xeon® Processors)
Expansion slots
2 Thunderbolt 3
5
(Supporting DisplayPort 1.2, USB 3.1 Gen2, PCIe Gen
3 devices)
1 SD UHS-II Flash Media slot (Supports next generation SD (Secure
Digital), backward compatible to SDHC, SDXC,
1 Integrated Smart Card Reader (Compatible with ISO 7816 compliant
Smart Cards PC/SC interface support)
2 Thunderbolt 3
5
(Supporting DisplayPort 1.2, USB 3.1 Gen2, PCIe
Gen 3 devices)
1 SD UHS-II Flash Media slot (Supports next generation SD (Secure
Digital), backward compatible to SDHC, SDXC,
1 Integrated Smart Card Reader (Compatible with ISO 7816 compli-
ant Smart Cards PC/SC interface support)
Graphics
Intel® HD
6
Graphics 530
8
Intel® HD
6
Graphics P530
8
Intel® Iris™ Pro Graphics P580
AMD® FirePro™ W5170M
NVIDIA® Quadro® M1000M
NVIDIA® Quadro® M2000M
NVIDIA® Quadro® M6000M
1
Intel® HD Graphics 530
8
Intel® HD Graphics P530
8
Intel® Iris™ Pro Graphics P580
AMD® FirePro™ W6150M
NVIDIA® Quadro® M1000M
NVIDIA® Quadro® M2000M
NVIDIA® Quadro® M3000M
NVIDIA® Quadro® M4000M
NVIDIA® Quadro® M5000M
Maximum supported displays
7
Up to 3 independent displays with Intel Integrated graphics, using
the system panel , VGA port, and two of the three following
ports: HDMI, Thunderbolt™ 3, Thunderbol1™ 3.
Up to 4 independent displays with hybrid graphics, using the
system panel, VGA port and 2 out of the three following ports:
HDMI, Thunderbolt™ 3, Thunderbolt™ 3
Up to 6 independent displays with hybrid graphics, when using the
optional ZBook Dock with Thunderbolt™ 3.
Up to 3 independent displays with Intel Integrated graphics,
using the system panel , VGA port, and two of the three
following ports: HDMI, Thunderbolt™ 3, Thunderbolt™ 3.
Up to 4 independent displays with hybrid graphics, using the
system panel, VGA port and 2 out of the three following ports:
HDMI, Thunderbolt™ 3, Thunderbolt™ 3
Up to 6 independent displays with hybrid graphics, when using
the optional ZBook Dock with Thunderbolt™ 3.
Controllers and HDDs
14,15
1TB 5400 rpm SATA, 2.5” Hard Drive
500 GB 7200 rpm SATA, 2.5” Hard Drive
500 GB 5400 rpm SATA SSHD (8 GB cache)
500 GB 7200 rpm SATA SED (Opal2)
500 GB 5400 rpm SSATA SED FIPS 140-2 compliant
256 GB M.2 SATA SED
256/512 GB, 1TB HP Z Turbo Drive (PCIe SSD)
500 GB, 1 TB 7200 rpm SATA 2.5” Hard Drive
500 GB 7200 rpm SATA 2.5” Hard Drive
500 GB SATA SATA SSHD (8 GB cache)
500 GB 7200 rpm SATA SED
500 GB 7200 rpm SATA SED FIPS 140-2 compliant
256 GB M.2 SATA Self Encrypting Drive (SED)
256/512 GB, 1TB HP Z Turbo Drive (PCIe SSD)
Remote Technology
HP Remote Graphics Software (RGS) HP Remote Graphics Software (RGS)
Communications
Integrated Intel® I219-LM Gigabit
21
Network Connection (vPro
congurations)
18,19
Intel® Dual Band Wireless-AC 8260 802.11 a/b/g/n/ac (2x2) WiFi and
Bluetooth® 4.2 combo (vPro)
18,19,23
Intel® Dual Band Wireless-AC 8260 802.11 a/b/g/n/ac (2x2) WiFi and
Bluetooth® 4.2 combo (non-vPro)
23
HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband
Module (optional)
23
HP hs3110 HSPA+ Intel® Mobile Broadband Module (optional)
23
Integrated Intel® I219-LM Gigabit
21
Network Connection (vPro
congurations)
18,19
Intel® Dual Band Wireless-AC 8260 802.11 a/b/g/n/ac (2x2) WiFi
and Bluetooth® 4.2 combo (vPro)
18,19 , 23
Intel® Dual Band Wireless-AC 8260 802.11 a/b/g/n/ac (2x2) WiFi
and Bluetooth® 4.2 combo (non-vPro)
23
HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband
Module
23
HP hs3110 HSPA+ Intel® Mobile Broadband Module
23
Family datasheet | HP Z Workstations
Mobile Workstations
