QuickSpecs HP xw9300 Workstation Overview HP recommends Microsoft® Windows® XP Professional 1. 2. 3. 4. Monitor (sold separately) 2004 Standard Keyboard 2-Button Scroll Mouse Front IO: 2 USB 2.0, IEEE-1394 (standard), headphone and microphone 5. 5.25"" external bay for optional diskette drive, optical drive or other 5.25"/3.5" device 6. 5 internal 3.5" bays, 3 external 5.25" bays 7. 2 PCI, 3 PCI-X slots 8. 2 PCI Express x16 Graphics Bus 9. Dual AMD Opteron™ processors 10.
QuickSpecs HP xw9300 Workstation Standard Features - Custom Components Processor and Speed – AMD Opteron Processor with 1 GHz HyperTransport bus, 1 MB L2 cache One of the following 246 (2.00 GHz) 248 (2.20 GHz) 250 (2.40 GHz) 252 (2.60 GHz) 254 (2.80 GHz) 256 (3.00 GHz) Dual-Core AMD Opteron Processor with 1 GHz HyperTransport bus, 1 MB L2 cache per core for a combined total of 2MB. 270 (2.00 GHz) 275 (2.20 GHz) 280 (2.40 GHz) 285 (2.
QuickSpecs HP xw9300 Workstation Standard Features - Custom Components 1st Hard Disk Drive – One of the following 2nd** Hard Disk Drive One of the following Windows XP Red Hat Linux Serial ATA 3Gb/s Hard Drive 80 GB SATA 3.0Gb/s Hard Drive (7,200 rpm) 32-Bit, 64-Bit WS3, WS4 250 GB SATA 3.0Gb/s Hard Drive (7,200 rpm) 32-Bit, 64-Bit WS3, WS4 500 GB SATA 3.0Gb/s Hard Drive (7,200 rpm) 32-Bit, 64-Bit WS3, WS4 Serial ATA 1.5Gb/s Hard Drives 74 GB SATA 1.
QuickSpecs HP xw9300 Workstation Standard Features - Custom Components 3rd Hard Disk Drive – One of the following 4th Hard Disk Drive – One of the following 5th Hard Disk Drive – One of the following Drive controllers Serial ATA 3Gb/s Hard Drive 3rd hard drive, 80 GB SATA 3.0Gb/s Hard Drive (7,200 rpm) 3rd hard drive, 250 GB SATA 3.0Gb/s Hard Drive (7,200 rpm) 3rd hard drive, 500 GB SATA 3.0Gb/s Hard Drive (7,200 rpm) Serial ATA 1.5Gb/s Hard Drives 3rd hard drive, 74 GB SATA 1.
QuickSpecs HP xw9300 Workstation Standard Features - Custom Components Factory Integrated RAID Windows XP Red Hat Linux* RAID 0 Configuration - Striped Array 32-Bit, 64-Bit WS3, WS4* RAID 0 Configuration - Data Array 32-Bit, 64-Bit WS3, WS4* RAID 1 Configuration - Mirrored Array 32-Bit, 64-Bit WS3, WS4* NOTE: Requires 2 identical hard drives (speeds, capacity, interface) NOTE: Hardware Controller supported by Linux except for any of the RAID features.
QuickSpecs HP xw9300 Workstation Standard Features - Custom Components 2nd Removable Storage Windows XP 32-Bit, 64Bit 32-Bit, 64Bit 32-Bit, 64Bit 32-Bit 48X CD-RW Drive 16X DVD-ROM drive 48X Combo CD-RW/DVD-ROM Drive Red Hat Linux WS3, WS4 WS3, WS4 WS3, WS4 16X DVD+/-RW, DL (Dual-Layer) with LightScribe (Lightscribe Software WS3, WS4 works with Windows only) NOTE: The RHEL3 U4 (x86) OS will operate correctly after some manual configuration steps.
QuickSpecs HP xw9300 Workstation Standard Features - Custom Components Graphics* Windows XP NVIDIA Quadro NVS 285* PCIe with TurboCache technology 32-Bit, 64(128 MB, VGA & DVI) Bit NVIDIA Quadro FX 540 PCIe (128 MB) 32-Bit, 64Bit NVIDIA Quadro FX 1400 PCIe (128 MB) – NVIDIA SLI capable 32-Bit, 64Bit NVIDIA Quadro FX 3450* PCIe (256 MB) – NVIDIA SLI capable 32-Bit, 64Bit NVIDIA Quadro FX 4500* PCIe (512 MB) 32-Bit, 64Bit Graphics NVIDIA Quadro G-Sync Card*** 32-Bit, 64Connectors Bit NVIDIA SLI Graphics Co
QuickSpecs HP xw9300 Workstation Standard Features - Specs Form factor Operating System (choice) Minitower Microsoft Windows XP Professional SP2 Microsoft Windows XP Professional SP2 x64 Edition OR Red Hat Enterprise Linux Workstation 3 Update 5 (support for x86 or EM64T) OR HP Installer Kit for Linux (includes drivers for 64-bit OS versions on xw9300, xw8200, xw6200, xw4200) Carbonite/Alloy metallic E- ATX (12" x 13") Color System Board Form Factor Processor Single or dual AMD Opteron 200 series proces
QuickSpecs HP xw9300 Workstation Standard Features - Specs Maximum Altitude (nonpressurized) Power Supply Interfaces Supported Operating 10,000 ft (3,000 m) Non-operating 30,000 ft (9,100 m) 700W wide-ranging, active Power Factor Correction 4 SATA interface (4 serial-ATA connectors), Ultra320 SCSI interface, 2 EIDE interface (1 EIDE connectors) supported for optical drives.
QuickSpecs HP xw9300 Workstation After-Market Options Processors Part Number 2nd AMD Opteron processor with AMD64 Technology & HyperTransport AMD Opteron 246 processor at 2.00 GHz with 1GHz HT bus & 1 MB of L2 cache AMD Opteron 248 processor at 2.20 GHz with 1GHz HT bus & 1 MB of L2 cache AMD Opteron 250 processor at 2.40 GHz with 1GHz HT bus & 1 MB of L2 cache AMD Opteron 252 processor at 2.60 GHz with 1GHz HT bus & 1 MB of L2 cache AMD Opteron 254 processor at 2.
QuickSpecs HP xw9300 Workstation After-Market Options U320 SCSI Back Panel connector (Uses HDCI, 32-Bit, 64-Bit WS3, WS4 AA658A HD68, or mini DB68 connectors) StorCase DX115 SATA Removable Enclosure EA332AA NOTE: All hard drives are supported with Red Hat Linux WS3 Update 5 and WS4 Update 1 (both x86 and EM64T) only when using the same type of drive. Drive mixing is not supported.
QuickSpecs HP xw9300 Workstation After-Market Options Networking NICs Broadcom 5751 Netxtreme Gigabit PCIe NIC Intel® Pro/1000 MT Gigabit PCI NIC Intel Pro/1000 PT Gigabite PCI Express NIC Intel Pro/1000 GT Gigabit PCI NIC Memory (DIMMs) PC3200 (DDR 400 MHz) ECC Registered DIMMs 512 MB PC3200 (DDR 400 MHz) ECC Registered (1 x 512 MB) 1 GB PC3200 (DDR 400 MHz) ECC Registered (1 x 1 GB) 4 GB (2x2GB) DDR400 ECC Registered (Duct) 8 GB DDR PC2700 (333 MHz) ECC Registered (2 x 4 GB) HP xw9300 2-GB DIMM Cooling
QuickSpecs HP xw9300 Workstation After-Market Options Removable Storage Windows XP Red Hat Linux Part Number 1.
QuickSpecs HP xw9300 Workstation Memory AMD Opteron processor with Direct Connect Architecture DDR SDRAM ECC REGISTERED MEMORY This chart does not represent all possible memory configurations. Each AMD Opteron processor has an integrated memory controller that supports ECC Registered 400 MHz (PC3200) or 333 MHz (PC2700) DDR memory only. Main memory is directly connected to the processor through the Direct Connect Architecture. There are 8 DIMM slots which provide 6.4 GB/s bandwidth per processor.
QuickSpecs HP xw9300 Workstation Memory DIMM Size Slot CPU 1 1 GB 2 GB 2 GB 2 GB 4 GB 8 GB 2 GB (dual) 4 GB (dual) 4 GB (dual) 6 GB (dual) 8 GB (dual 8 GB (dual) 12 GB (dual) 16 GB (dual) 16 GB (dual) 32 GB (dual) Socket set 1 512 MB 512 MB 1 GB 1 GB 512 MB 512 MB 512 MB 512 MB 1 GB 1 GB 2 GB 2 GB 512 MB 512 MB 1 GB 1 GB 512 MB 512 MB 1 GB 1 GB 2 GB 2 GB 1 GB 1 GB 2 GB 2 GB 4 GB 4 GB 2 GB 2 GB 4 GB 4 GB CPU2 Socket set 3 512 MB 512 MB 1 GB 2 GB Socket set 2 Socket set 4 512 MB 512 MB 1 GB 2 GB 51
QuickSpecs HP xw9300 Workstation Storage Tower configuration Quantity Supported Position Supported Controller 1 3 5 3 1, 2, 3 4, 5, 6, 7, 8 Diskette IDE SATA or SCSI Convertible Minitower Optional Diskette Drive 5.25” Storage Drive Bays 3.5” Storage Drive Bays with acoustic dampening rail assemblies SCSI and SATA may be mixed in a Windows configuration, only the primary drive may be SATA. Linux does not support SATA controller or mixing SATA and SCSI drives.
QuickSpecs HP xw9300 Workstation Additional Technical Specifications System Board Architecture Chipset Super I/O Controller System Board Form Factor Processor Socket DIMM Connectors (DDR1, 2.5V) PCIe Connectors Integrated Graphics PCI Connectors (5.
QuickSpecs HP xw9300 Workstation Additional Technical Specifications ASF 1.0 (Alert Standard Format) Power Supply Connectors Power Switch, Power LED & Hard Drive LED Header S3 Support Password Clear Header Riser Connector HDD activity LED Header No Yes, 24-pin Main Power, 8-pin CPU, 6-pin Auxiliary Yes Yes Yes None Yes DA - 12186 Worldwide QuickSpecs — Version 25 — 4.30.
QuickSpecs HP xw9300 Workstation Technical Specifications Cooling Cooling Solutions Supported Power Supply Fan Processor Fan-Heatsink Chassis Fan (front) Chassis Fan (rear) Internal Speaker Power Supply 9 outputs Full Ranging Input Active Power Factor Correction (APFC) (Input Current is nearly ½ a non-APFC PS) Passive Power Factor Correction (PFC) Operating Voltage Range Rated Voltage Range Rated Line Frequency Operating Line Frequency Range Rated Input Current Maximum Rated Power Heat Dissipation PS Siz
QuickSpecs HP xw9300 Workstation Technical Specifications Remote System Allows a new or existing system to boot over the network and download software, including the Installation via F12 (PXE) operating system (Remote Boot from Server) System/Emergency ROM Recovers corrupted system BIOS Flash Recovery with Video ROM revision levels Identifies system ROM revision levels and reports in ROM-based F10 setup Version is stored in an industry standard memory location (SMBIOS) so that management SW applications c
QuickSpecs HP xw9300 Workstation Technical Specifications Per-slot control Adaptive cooling Pre-boot diagnostics Allows individual slot configuration (option ROM.
QuickSpecs HP xw9300 Workstation Technical Specifications Monitoring (CRC Checking) Drive Self Tests (DPS) proactive notification of hard drive data transmission problems with recommendations for enhancing system performance. It detects all the following errors' types: single bit errors double bit errors an odd number of errors error bursts up to 32-bits long Drive Protection System (Adaptec and LSI SCSI controllers do not offer DPS) A diagnostic hard drive self test.
QuickSpecs HP xw9300 Workstation Technical Specifications Serviceability Features of System Access panel Tool-less, one-handed Optical drives Tool-less Floppy drive Tool-less Hard drives Tool-less Expansion cards Tool-less Green user touch points Yes, on tool-free internal chassis mechanisms Color-coordinated cables Yes and connectors Memory Tool-less, can be upgraded without removing any internal components CPUs Tool-less, can be upgraded without removing any internal components Chassis fan removal Tool-
QuickSpecs HP xw9300 Workstation Technical Specifications Service and Support On-site Warranty and Service (Note 1): This three-year, limited warranty and service offering delivers three years of on-site, next business-day (Note 2) service for parts and labor and includes free telephone support (Note 3) 24 x 7.
QuickSpecs HP xw9300 Workstation Technical Specifications - Audio AC97 Integrated ADI 1981B Audio Type AC ‘97 Stereo Codec FM Synthesis Support OPL3 FM Synthesis Support Sound Blaster Compatibility Audio Jacks Integrated Yes Yes – Yamaha XG Lite Yes Yes Microphone-In (20-K ohm Input Impedance); rear stereo and front analog microphone ports Line-In (12-K ohm Input Impedance) Line-Out * (less than 800 ohms Output Impedance, expects at least a 10-K ohm load) Headphone-Out (2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Audio Enhanced SoundFont up to 24-bit resolution support 24-bit/96kHz DACs 24-bit/192kHz Voice Support 128 voices Max. Channels in 3D 7.1 Positional Audio EAX® ADVANCED Yes including EAX® MacroFX™, EAX® PurePath™ and Environment HD™ 5.0 support FlexiFX™ Connectors FlexiJack (Performing a 3-in-1 function, Digital In / Line In / Microphone) via 3.50 mm minijack Line level out (Front / Rear / Center / Subwoofer / Rear Center) via 3.
QuickSpecs HP xw9300 Workstation Technical Specifications - Audio requirements Hard disk Operating System 600MB free space Available PCI 2.1 slot for the audio card CD-ROM/CD-RW or CD/DVD-ROM required for software installation Microsoft® Windows® XP Service Pack 2 (SP2) DA - 12186 Worldwide QuickSpecs — Version 25 — 4.30.
QuickSpecs HP xw9300 Workstation Technical Specifications - Communications Integrated NVIDIA LAN- Connector on-Motherboard Controller RJ-45 NVIDIA Gigabit Controller with Marvell PHY Data rates supported 10/100/1000 Mbps Compliance IEEE 802.
QuickSpecs HP xw9300 Workstation Technical Specifications - Communications Intel Pro/1000 MT Gigabit PCI NIC Connector Controller Memory Data rates supported Compliance RJ-45 Intel 82540EM Gigabit Controller Integrated 96Kb frame buffer memory 10/100/1000 Mbps IEEE 802.1A, 802.1P, 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u compliant, 802.3x flow control Bus architecture PCI 2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Controllers LSI Logic LSI53C1030 Bus architecture Ultra320 SCSI Onboard Number of supported Controller devices Interface protocol Host bus transfer rate SCSI data transfer rate SCSI Bus Internal connector External connector Total connectors Plug and Play Support Dimensions (H x L) Operating system support Kit contents PCI-X 5 internal SCSI devices U320 SCSI Controller LSI 20320AR RAID 0,1 including external connector (required with SCSI HDDs)
QuickSpecs HP xw9300 Workstation Technical Specifications - Controllers Adaptec SCSI RAID 2120S Card Dimensions (H x D) RAID level Data Transfer Rate Cache Memory Device Support Bus Type 2.5 x 6.6 in (6.4 x 16.
QuickSpecs HP xw9300 Workstation Technical Specifications - Hard Drives Serial ATA 3.0-Gb/s Hard Drives 500 GB Capacity Height Width 500,107,862,016 bytes 1.0 in (2.54 cm) Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm) Interface Serial ATA (3.0 Gb/s), Native Command Queuing enabled Synchronous Transfer Up to 3 Gb/s Rate (Maximum) Buffer 16 MB Seek Time (typical Single Track 1.3 ms reads, includes controller Average 20.
QuickSpecs HP xw9300 Workstation Technical Specifications - Hard Drives Serial ATA 1.5-Gb/s Hard Drives (10,000 rpm) 80 GB Capacity Height Width 80,026,361,856 bytes 1.0 in (2.54 cm) Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm) Interface Serial ATA (3.0 Gb/s) Synchronous Transfer Up to 3 Gb/s Rate (Maximum) Buffer 8 MB Seek Time (typical Single Track 2 ms reads, includes controller Average 9.
QuickSpecs HP xw9300 Workstation Technical Specifications - Hard Drives 146 GB Capacity 146,815,737,856 bytes Height 1.0 in (2.54 cm) Width 3.5 in (8.9 cm) Interface 68 pin LVD SCSI Synchronous Transfer 320 MB/s Rate (Maximum) Buffer 8 Mbytes Seek Time (typical Single Track reads, includes controller Average overhead, including Full-Stroke settling) 0.3 msec <4.5 msec <11.
QuickSpecs HP xw9300 Workstation Technical Specifications - Hard Drives Interface 68 pin LVD SCSI Synchronous Transfer 320 MB/s Rate (Maximum) Buffer 8 Mbytes Seek Time (typical Single Track 0.3 msec reads, includes controller Average <4.5 msec overhead, including Full-Stroke <11.0 msec settling) Rotational Speed 15,000 rpm Logical Blocks 143,374,738 Operating Temperature40° to 130°F (5° to 55° C) 146 GB Capacity 146,815,737,856 bytes Height 1.0 in (2.5 cm) Width 3.5 in (8.
QuickSpecs HP xw9300 Workstation Technical Specifications - Removable Storage USB Disk on Key Dimensions (HxWxD) Weight USB Specification Transfer Rate Storage Media Power Supply Capacity 0.9 x 0.7 x 3.9 in (2.3 x 1.8 x 9.8 cm) 0.05 lb (0.02 kg) 2.0 Read-1023 KB/Sec; Write-850 KB/Sec Solid state flash memory, no moving parts USB Bus-powered, no external power required 256 MB DA - 12186 Worldwide QuickSpecs — Version 25 — 4.30.
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices PS/2 OR USB '04 Standard Keyboard Physical characteristics Electrical Mechanical Keys 104, 105, 106, 107, 109 layout (depending upon country) Dimensions (L x W x H) 18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm) Weight 2 lb (0.
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices Electrical Mechanical Operating voltage Power consumption System interface ESD EMI - RFI MicrosoftPC 99 - 2001 Languages Keycaps Switch actuation Switch life + 5VDC ± 5% 100-mA maximum (with four LEDs ON) USB Type A plug connector CE level 4, 15-kV air discharge Conforms to FCC rules for a Class B computing device Functionally compliant 30+ available Low-profile design 55-g nominal peak force with tactile feedback 20 milli
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices Communication Landing mechanism Interface modes Reader performance interface Electro-magnetic standards Operating system support From card Programmable from 9,600 baud to 115,200 baud From computer Up to 38,400 baud Contact device Friction contact Card insertions Up to 100,000 rating insertion cycles USB communications through USB port SCM protocol Automatic card insertion/removal detection USB connection Europe 89/336/
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices Sharp Oberthur Memory Cards Atmel Java Card CosmopollIC v4 CosmopollIC v4.1 Cosmo ID-One GalatIIC v2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices HP PS/2 Scroll Mouse Dimensions Weight Environmental Electrical 3.8 x 6.3 x 11.6 cm (1.5 x 2.5 x 4.6 in) 4.
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices HP 2-button Optical Scroll Mouse (USB) Dimensions (H x L x W) Weight Cable length System requirements 1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm) 0.27 lb (0.12 kg) 72.8 in (185 cm) Microsoft Windows XP Professional, Microsoft Windows XP Professional x64 Edition, Red Hat Enterprise Linux Workstation 3 and 4 HP 3-Button Optical USB Mouse Dimensions/Weight Height 1.5 in (3.76 cm) Length 4.5 in (11.56 cm) Width 2.4 in (6.
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices HP SpaceMouse Plus USB Physical characteristics Environmental Mechanical USB Specifications Dimensions (H x W x D) 7.4 x 4.72 x 1.73 in (18.8 x 12.0 x 4.4 cm) Cap Diameter 2 x 6.5 x 6.6 mm Weight 1.5 lb (0.
QuickSpecs HP xw9300 Workstation Technical Specifications - Input/Output Devices Regulatory Approvals UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN 50082, IEC 1000 4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick DA - 12186 Worldwide QuickSpecs — Version 25 — 4.30.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices 48X CD-ROM Drive Form Factor Mounting Orientation Interface Dimensions (HxWxD) Weight Data Transfer Rates Read Media and Formats Read 5.25-in, half-height, tray load Horizontal or vertical ATAPI/EIDE 1.63 x 5.83 x 7.27 in (4.13 x 14.6 x 18.5 cm) 1.76 lb (0.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Supplied Software 16X/40X DVD-ROM Drive with +R Read Support None Height 5.25-in, half-height, tray load Interface Type ATAPI/EIDE Dimensions (W x H x D) 5.88 x 1.71 x 7.87 [max] in (149.5 x 43.25 x 200.0 [max] mm) (external, excluding bezel) Disc Formats DVD-ROM (single and dual layer); DVD-video; DVD-R version 1.0 and 2.0; DVD-RW version 1.0 and 1.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Operating Environmental (all conditions noncondensing) Certifications, Approvals Operating Systems Supported Kit Contents HP 48X CD-RW Temperature (operating) 41° to 122° F (5° to 50° C) Relative Humidity 10% to 85% (operating) Maximum Wet Bulb 86° F (30° C) Temperature (operating) MMC II support, multi-read certification, Microsoft WHQL certification, ACA AS/NZS 3548 class B, CNS 13438, C.I.S.P.R.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Write Methods Disc-at-once, session-at-once, track-at-once, incremental fixed and variable packet, multisession Access Times CD-ROM Mode 1 < 125 ms (typical reads, including Full Stroke CD < 210 ms settling) Start-up Time (typical) < 7 s (single session), < 30 s (multi-session) Stop Time (typical) <4s Write Buffer Size 2 MB Data Transfer Modes PIO Mode 4 (16.6 MB/s); Multi-word DMA mode 2 (16.6 MB/s); UltraDMA Mode 2 (33.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Media and Formats Read Writeable Disc Parameters Data Transfer Rates Write Media and Formats Write Write Methods Access Times Random DVD (typical reads, including Random CD settling) Full Stroke DVD Full Stroke CD Startup Time (single) Startup Time (multisession) Stop Time (typical) CD Media: stamped; CD-R; CD-RW (LS, HS, US) CD Capacities: 180 MB (mode 2, 8 cm); 540 MB (mode 1, 12 cm); 650 MB (mode 2, 12 cm); 700 MB (Mode 2
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Cache Buffer Data Transfer Modes 2 MB (minimum) ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA mode 2 (16.7 MB/s); ATA UltraDMA Mode 3 (44 Mbytes/s) Power Source Four-pin, DC power receptacle DC Power Requirement5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p DC Current 5 VDC (< 1000 mA typical, < 1600 mA maximum) 12 VDC (< 600 mA typical, < 1400 mA maximum) Total Drive Power < 2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Media and Formats Read Writeable Disc Parameters Data Transfer Rates Write Media and Formats Write CD-ROM, CD-R, CD-RW, CD-Audio read 16-40X (2400 to 6000 KB/s CAV) CD Media: stamped; CD-R; CD-RW (supports AM2) (LS, HS, US) CD Capacities: 180 MB (mode 2, 8 cm); 540 MB (mode 1, 12 cm); 650 MB (mode 2, 12 cm); 700 MB (Mode 2, 12 cm, 80-minute) CD Formats: CD-DA, CD-ROM (Mode 1 and 2), CD-XA (Mode 2, Form 1 and 2), Photo CD (Sin
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Write Methods LightScribe Direct Disc Media Supported Labeling Parameters Resolution Labeling Times Access Times Random DVD (typical reads, including Random CD settling) Full Stroke DVD Full Stroke CD Startup Time (single) Startup Time (multisession) Stop Time (typical) Cache Buffer Data Transfer Modes Power Audio Output DVD Media: DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-RW DVD Capacities: 4.7 GB (DVD-5), 8.54 GB (DVD-9), 4.
QuickSpecs HP xw9300 Workstation Technical Specifications - Optical Devices Operating Conditions (all conditions noncondensing) Temperature 41° to 122° F (5° to 50° C) Relative humidity 10% to 90% Maximum wet bulb 86° F (30° C) temperature Certifications, MMC-4 compliant, multi-read compliant, Microsoft WHQL certification, Approvals ACA AS/NZS 3548 class B, BSMI CNS 13438, CE Mark, C.I.S.P.R. Pub 22, TUV or VDE EN60950, EN 55022, EN55024, EMKO EN60950, EN 60825-1, UL 60950, CSA C22.
QuickSpecs HP xw9300 Workstation Technical Specifications - Graphics NVIDIA Quadro NVS Form Factor 285 PCIe Graphics with TC Technology Graphics Controller Nvidia Quadro NVS 285 128MB PCIe Dual Head Low profile, both ATX and low profile brackets included Integrated Quadro 285 2D graphics processor unit (GPU) Bus Type PCI-Express Memory 128 MB DDR (64 MB local frame buffer plus 64 MB of shared system memory via TurboCache technology) NOTE: The graphics card uses part of the total system memory (RAM) for g
QuickSpecs HP xw9300 Workstation Technical Specifications - Graphics Supported graphics APIs Available graphics drivers Maximum Resolution NVIDIA Quadro FX 1400 PCI-Express Graphics Controller Form Factor Graphics Controller Bus Type RAMDAC Memory Connectors Multi-monitor support Additional product features Shading architecture Supported graphics APIs Long fragment programs (up to 65,536 instructions) Long vertex programs (up to 65,536 instructions) Looping and subroutines (up to 256 loops per ver
QuickSpecs HP xw9300 Workstation Technical Specifications - Graphics Available graphics drivers Maximum Resolution NVIDIA Quadro FX 3450 Graphics Controller HP-tested: Microsoft Windows XP, Windows 2000 and Linux HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/eng/software_drivers.html.
QuickSpecs HP xw9300 Workstation Technical Specifications - Graphics Display Resolution Support nView Architecture Supported Graphics APIs Available Graphics Drivers NVIDIA Quadro FX 4500 Graphics Controller Graphics Controller Dual Link DVI- I output-drives digital displays at resolutions up to 3840 x 2400 @ 24 Hz Single Link DVI-I output drives digital displays at resolutions up to 1920 x 1200 @ 75 Hz Internal 400 MHz DACs - Two analog displays up to 2048 x 1536 @ 75 Hz each Advanced multi-display d
QuickSpecs HP xw9300 Workstation Technical Specifications - Graphics High Level Shader Languages High-Resolution Antialiasing Display Resolution Support nView Architecture Supported Graphics APIs Available Graphics drivers Optimized compiler for Cg and Microsoft HLSL OpenGL 2.0 and DirectX 9.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors HP L1755 Flat Panel Monitor Panel Video/Other Inputs Type Viewable Image Area (diagonal) Screen Opening (WxH) Viewing Angle (typical) Brightness (typical) Contrast Ratio (typical) Response Rate (typical) Pixel Pitch Color Depth Support Plug and Play Self Powered USB 2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors AssetControl On Screen Display (OSD) Controls Default Color Temperature Buttons or Switches Languages User Controls Power Power Supply Input Power Nominal Current Frequency Average Typical Power Consumption Maximum Power Saving Off Mode Mechanical Power Cable Length Dimensions (H x W x D) Weight Bezel Width Tilt Range Swivel Range Height Adjustable Pivot Rotation Base Environmental Temperature – Yes (accessible on HP Compaq Bu
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Options Other Operating Temperature – Nonoperating Humidity – Operating Humidity – Nonoperating Altitude – Operating Altitude – Nonoperating HP Desktop Access Center – Part number: DK985A -4° to 140° F (-20° to 60° C) 20% to 80% 5% to 95% 0 to 13,000 ft (0 to 4,000 m) 0 to 40,000 ft (0 to 12,192 m) Features integrated microphone/headset jacks, dual function headset for phone/PC support, a MultiBay slot for adding an optical drive (s
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Warranty Languages Color VESA Mounting English, Canadian French, Latin America Spanish, Brazilian Portuguese, Danish, Dutch, Finnish, French, German, Italian, Norwegian, Spanish, Swedish, Bahasa Indonesian, Simplified Chinese, Traditional Chinese, and Korean Carbonite, two-tone carbonite and silver (EMEA only) Yes (swing arm/wall mount not included); base must be removed for mounting options) Yes (standard 4 hole pattern, 100 mm) VESA
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Video Cable Signal Interface/ Performance VGA to VGA, DVI-D to DVI-D, and DVI-I to VGA Video Cable Length 78 in (2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Input Power Nominal Current Frequency Average Typical Power Consumption Maximum Power Saving Off Mode Mechanical Power Cable Length Dimensions (H x W x D) Weight Bezel Width Tilt Range Swivel Range Height Adjustable Pivot Rotation Base Environmental Options Temperature – Operating Temperature – Nonoperating Humidity – Operating Humidity – Nonoperating Altitude – Operating Altitude – Nonoperating Desktop Access Center supply 100 ~
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors more information, refer to the HP Desktop Access Center QuickSpecs. HP Flat Panel Speaker Powered directly by the monitor, seamlessly Bar attaches to the monitor's bezel to bring full multimedia support to select HP flat panel monitors. Features dual speakers with full sound range and external jack for headphones. Sold separately, part number PF804AA. For more information, refer to the HP Flat Panel Speaker Bar QuickSpecs.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors L2035 On Screen Display (OSD) Controls Signal Interface/ Performance Viewable Image Area 20.1 in (51 cm) (diagonal) Screen Opening 16.2 x 12.17 in (41.1 x 30.9 cm) (W x H) Viewing Angle (typical)*Up to 170° H/170° V (10:1 minimum contrast ratio) Brightness (typical* Up to 250 nits (cd/m2) Contrast Ratio (typical)* Up to 400:1 Response Rate 16 ms (typical, rise + fall) (typical)* Pixel Pitch 0.255 mm Color Depth Support 16.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Video Input Default Color Temperature Plug and Play Input Signal Input Impedance Sync Input Power Video Cable Video Cable Length Input Power Frequency Maximum Power Saving Power Cable Length Mechanical Environmental 6500 K Yes Four connectors, including one 15-pin mini Dsub VGA, one DVI-I (VGA analog and digital input), one composite video, and one s-video 75 ohms ± 10% Separate sync (HSYNC/VSYNC); composite sync, Sync on Green V
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Options Sold separately, the HP Desktop Access Center features integrated microphone/headset jacks, dual function headset for phone/PC support, a MultiBay slot for adding an optical drive (sold separately), and four USB ports for easy integration of third-party digital solutions; part number DK985A. For more information, refer to the HP Desktop Access Center QuickSpecs.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors LP2065 On Screen Display (OSD) Controls Viewable Image Area 20.1 in (51 cm) (diagonal) Screen Opening 16.2 x 12.17 in (41.1 x 30.9 cm) (W x H) Viewing Angle (typical)*Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio) Brightness (typical* Up to 300 nits (cd/m2) Contrast Ratio (typical)* Up to 800:1 Response Rate 8 ms (gray to gray), 16 ms (rise + fall) (typical)* Pixel Pitch 0.255 mm Color Depth Support 16.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Input Signal Power Mechanical Environmental Options Four connectors, including one 15-pin mini Dsub VGA, one DVI-I (VGA analog and digital input), one composite video, and one s-video Self Powered USB 2.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Speaker Bar - Part number: EE418AA Other Speaker Bar seamlessly attaches to the monitor's lower bezel to bring full audio support to select HP flat panel monitors. Features include dual speakers with full sound range and external jack for headphones. Sold separately. For more information, refer to the HP Silver Flat Panel Speaker Bar QuickSpec.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Certain restrictions and exclusions apply. For details, contact HP Customer Support. HP Flat Panel Monitor Panel L2335 On Screen Display (OSD) Controls Signal Interface/ Performance Type 23-inch Active Matrix TFT (thin film transistor) Viewable Image Area 23 in (58.4 cm) (diagonal) Screen Opening 19.53 x 12.24 in (49.6 x 31.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Video Input User Programmable Modes Anti-Glare Anti-Static Default Color Temperature Yes, 10 Plug and Play Input Signal Yes Five connectors, including one 15-pin mini Dsub VGA, one DVI-I (VGA analog and digital input), one composite video, one s-video, component video 75 ohms ± 10% Separate sync (HSYNC/VSYNC); composite sync, Sync on Green VGA to VGA; VGA to DVI-I; DVI-D to DVI-I 5.9 ft (1.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors Options HP Desktop Access Center Other Accessories Included Sold separately, the HP Desktop Access Center Features integrated microphone/headset jacks, dual function headset for phone/PC support, a MultiBay slot for adding an optical drive (sold separately), and four USB ports for easy integration of third-party digital solutions; part number DK985A. For more information, refer to the HP Desktop Access Center QuickSpecs.
QuickSpecs HP xw9300 Workstation Technical Specifications - Monitors © Copyright 2006 Hewlett-Packard Development Company, L.P. All rights reserved. HP and the HP logo are trademarks of the Hewlett Packard Company in the U.S. and/or other countries. Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and/or other countries. NVIDIA and Quadro are trademarks of NVIDIA Corporation. All other product names mentioned herein may be trademarks of their respective companies.
