HP Spectre x360 Convertible PC Model numbers: 13-w000 - 13-w099 Model numbers: 13-ac000 - 13-ac099 Maintenance and Service Guide
Table Of Contents
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement preliminary requirements
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS)
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Backing up, restoring, and recovering
- Power cord set requirements
- Recycling
- Index
2 External component identication
Right side
Component Description
(1) Volume button Controls speaker volume on the computer.
(2) USB Type-C power connector and Thunderbolt
ports (2)
Connects an AC adapter that has a USB Type-C connector,
supplying power to the computer, and if needed, charging the
computer battery.
– or –
Connects and charges a USB device that has a Type-C connector,
such as a cell phone, camera, activity tracker, or smartwatch,
and provides high-speed data transfer.
– or –
Connects a display device that has a USB Type-C connector,
providing display output.
NOTE: Your computer may also support a Thunderbolt docking
station.
(3) AC adapter and battery light
●
White: The AC adapter is connected and the battery is fully
charged.
●
Blinking white: The AC adapter is disconnected and the
battery has reached a low battery level.
●
Amber: The AC adapter is connected and the battery is
charging.
●
O: The battery is not charging.
4 Chapter 2 External component identication
