HP Spectre x360 Convertible PC Model numbers: 13-w000 - 13-w099 Model numbers: 13-ac000 - 13-ac099 Maintenance and Service Guide
Table Of Contents
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement preliminary requirements
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS)
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Backing up, restoring, and recovering
- Power cord set requirements
- Recycling
- Index
Item Component Spare part number
(1) Display assembly (full hinge-up; includes display panel cable, microphones, hinges, webcam,
and wireless antenna cables and transceivers)
Models: 13-w000 – 13-w099 907334-001
Models: 13-ac000 – 13-ac099; display – FHD; computer color – natural silver 918030-001
Models: 13-ac000 – 13-ac099; display – FHD; computer color – dark ash silver 918031-001
Models: 13-ac000 – 13-ac099; display – UHD; computer color – natural silver 918032-001
Models: 13-ac000 – 13-ac099; display – UHD; computer color – dark ash silver 918033-001
(2) Top cover with keyboard (includes keyboard cable and keyboard backlight cable)
NOTE: For a detailed list of keyboard country codes, see Top cover and keyboard on page 50.
Models: 13-w000 – 13-w099; computer color – natural silver 907335-xx1
Models: 13-ac000 – 13-ac099; computer color – natural silver 918027-xx1
Models: 13-ac000 – 13-ac099; computer color – dark ash silver 918028-xx1
(3) TouchPad
Models: 13-w000 – 13-w099 907338-001
Models: 13-ac000 – 13-ac099 918034-001
(4) TouchPad cable 907332-001
(5) Speakers, front (includes left and right speakers and cables) 907343-001
(6) Speakers, rear (includes left and right speakers and cables) 907344-001
(7) Heat sink (includes replacement thermal material) 907557-001
Fan Kit, includes: 907333-001
(8) Heat sink fan
(9) Rear fan
(10) System board (includes a graphics subsystem with UMA memory and replacement thermal material) equipped with:
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows 10 operating system
Models: 13-w000 – 13-w099
●
Intel Core i7-7500U processor, 16 GB of system memory 907558-xx1
●
Intel Core i7-7500U processor, 8 GB of system memory 907559-xx1
●
Intel Core i5-7200U processor, 8 GB of system memory 907560-xx1
●
Intel Core i5-7200U processor, 4 GB of system memory 907561-xx1
Models: 13-ac000 – 13-ac099
●
Intel Core i7-7560U processor, 16 GB of system memory 918040-xx1
●
Intel Core i7-7500U processor, 16 GB of system memory 918042-xx1
●
Intel Core i7-7500U processor, 8 GB of system memory 918041-xx1
16 Chapter 3 Illustrated parts catalog
