HP Spectre x360 Convertible PC Model numbers: 13-w000 - 13-w099 Model numbers: 13-ac000 - 13-ac099 Maintenance and Service Guide

5 Removal and replacement procedures for
Authorized Service Provider parts
NOTE: This chapter provides removal and replacement procedures for Authorized Service Provider only
components. Components described in this chapter should only be accessed by an authorized service
provider. Accessing these components can damage the computer or void the warranty.
There are as many as 44 screws that must be removed, replaced, and/or loosened when
servicing the computer. Make special note of each screw size and location during removal and replacement.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Bottom cover
Description Spare part number
Bottom cover: Models: 13-w000 – 13-w099 907329-001
Bottom cover; models: 13-ac000 – 13-ac099; computer color – natural silver 918025-001
Bottom cover; models: 13-ac000 – 13-ac099; computer color – dark ash silver 918026-001
Before disassembling the computer, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation,
turn the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
Remove the bottom cover:
1. Position the computer upside down with the front toward you.
2. Remove the two rubber feet from the top of the bottom cover (1).
