Speaker, right rear
Description Spare part number
Speaker, right rear (includes cable) 907344-001
Before removing the right rear speaker, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation,
turn the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 24), and then remove the following components:
a. Battery (see Battery on page 26).
b. Fan (see Heat sink fan on page 30).
c. System board (see System board on page 39).
Remove the right rear speaker:
1. Remove the two Phillips PM2.0×3.5 screws (1) that secure the speaker to the computer.
2. Remove the speaker (2).
Reverse this procedure to install the right rear speaker.
