HP PageWide MFP Managed E77650dn, E77660dn - Certificate of Volatility

Mass Storage
Does the device contain mass storage memory (Hard Disk Drive, Tape Backup)?
Yes No If Yes please describe the type, size, function, and steps to clear the memory below
Type (HDD, Tape, etc):
HDD
Size:
320 GB
User Modifiable:
Yes No
Function:
System firmware and firmware
upgrade. System control data,
user preferences, variables
and encrypted job storage and
PIN printing.
Steps to clear memory:
User preferences and variables
cleared by performing various resets
via “Support” menu.
Encrypted job storage and PIN
printing Sanitization must be
performed using the printer’s
Embedded Web Server (EWS). Using
a web browser on the same network
as the printer, browse to the printer’s
IP address. Select the
“Security” tab at the top, and then
from the left navigation bar, select the
“Security->Protect Stored Data” menu
items. Select the types of files to be
erased and click on the “Apply”
button.
USB
Does the item accept USB input and if so, for what purpose (i.e. Print Jobs, device firmware updates, scan upload)?
Yes No If Yes please describe below
Purpose is for Print Jobs, Device FW updates, scan uploads and 3rd part application loading.
Can any data other than scan upload be sent to the USB device)?
Yes No If Yes please describe below
Diagnostic service logs can be uploaded. Back-up of encrypted system settings. Supports Hardware Integration Pocket
(HIP) devices.
Additional information:
This product has both a USB device port and 2 USB host ports. Data on the USB host ports can be accessed from the device port.
Also, an internal mini-B USB port enables an accessory option where a Hardware Integration Pocket (HIP) device can be added. The
HIP option conforms to the HIP protocol and enables both HP and 3rd party hardware/software. The HIP device does not ship with the
product and is added by the user as an option.
RF/RFID
Does the item use RF or RFID for receive or transmit of any data including remote diagnostics. (e.g. Cellular phone,
Bluetooth) Yes No If Yes please describe below
Purpose:
Frequency:
Bandwidth:
Modulation
Effective Radiate Power (ERP):
Specifications:
Other Transmission Capabilities
Does the device employ any other methods of non-wired access to transmit or receive any data whatsoever (e.g. anything
other than standard hard wired TCP/IP, direct USB, or parallel connections)? Yes No If Yes please describe below:
Purpose:
Frequency:
Bandwidth:
Modulation:
Effective Radiate Power (ERP):
Specifications
Other Capabilities
Does the device employ any other method of communications such as a Modem to transmit or receive any data
whatsoever? Yes No If Yes please describe below:
Purpose:
Specifications:
Author Information
Name Title Email Business Unit
Mark Irwin
Technical Marketing Engineer
[e-mail]
IPG
Michael Johnston
System Engineer
[e-mail]
IPG
Date Prepared: 1/15/2018
