IDU R2561 User Guide 1 About this Guide 1 About this Guide 1.1 Prerequisite Skills and Knowledge To use this document effectively, you should have a working knowledge of Local Area Networking (LAN) concepts and wireless Internet access infrastructures. In addition, you should be familiar with the following: Hardware installers should have a working knowledge of basic electronics and mechanical assembly.
IDU R2561 User Guide 2 Introduction 2 Introduction 2.1 Product Overview IDU R2561 is an Indoor CPE. Support 2 LAN ports and 1 VoIP port Support HTTPs Web GUI 2.2 Product Package Number Item Q'ty 1 Indoor Router 1 2 Power Adapter 1 If any item of mentioned above is missing or damaged, please contact our customer support immediately. 2.3 Connectors WAN : One RJ-45 connector for connecting to the ODU LAN port. Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 2 Introduction Figure 2-1 IDU Rear Panel Figure 2-2 IDU Front Panel Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 2 Introduction 2.4 LED Indicators Table 2-1 IDU R2561 LED Indicators as following table Numbe r LED name Color LED Behavior Status Indication 1 Main Power Green On Power On Off Power Off On System is connected Blinking System is upgrading Off System is disconnected Blinking Ethernet connected Off No Ethernet connected On Enable 2.4G Wi-Fi Blinking Data transmition Off Disable 2.
IDU R2561 User Guide 2 Introduction 2.5.2 Connecting the Cable Step 1 Physical connection as following 1. Connect the Ethernet cable to the RJ45 ports of IDU R2561 and ODU. 2. Connect the Ethernet cable from the computer to one of the IDU R2561's Ethernet Ports. 3. Connect the supplied power adapter to the IDU R2561. The PWR LED shines a steady green when device ready. 4. Mounting the Device.
IDU R2561 User Guide 3 Web Interface 3 Web Interface 3.1 Login to Web-GUI Step 1 Open the Web browser and enter the default IP address of the device, which is: 192.168.1.1 Step 2 Enter the default Username (admin) and Password (IDU@huawei) to access advanced interface or enter the default Username (user) and Password (LTE@Endusr) to access web management interface.
IDU R2561 User Guide 3 Web Interface Figure 3-1 Web UI - Normal Figure 3-2 Web UI - V Incorrect Username or Password Figure 3-3 Web UI - V Enter incorrect Username or Password three times Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 3 Web Interface If you're successfully connected to the Internet but cannot view webpages in Internet Explorer 8, maybe the settings of your browser is changed by some reasons. Suggest you to RESET your browser or follow below steps. 1. Open IE8 browser -> F12 developer tools 2. Browser Mode -> Internet Explorer 8 3.2 Function Button Function button is located at each Web UI page Top-Right corner. REBOOT Force device to initial a reboot.
IDU R2561 User Guide 3 Web Interface Figure 3-4 Device Status Operation Mode The mode to forward data packets between Internets. 2.4GHz Wi-Fi 2.4GHz Wi-Fi SSID Service Set ID (SSID) that identifies the Wi-Fi network. 5GHz Wi-Fi 5GHz Wi-Fi SSID Firewall Here displayed your current firewall level; there are three default configurations for you to select: Low/Medium/High or you can select Custom to configure by your preference. For more detail please refer to Basic> Firewall section.
IDU R2561 User Guide 3 Web Interface The reason for last device reboot (e.g. Device auto, Software Upgrade, etc.). Time Server The NTP (Network Time Protocol) server address. Click the "Refresh" button manual update the current status. Click the "Auto" button auto update the current status. 3.3.2 Status > Telephony Status The Telephony Status displays a summary of the VoIP registration .
IDU R2561 User Guide 3 Web Interface Click the "Refresh" button manual update the current status. Click the "Auto" button auto update the current status. 3.3.3 Status > Network Status Figure 3‑ 6 Network Status Duration The time period of active WAN connection. Connection Status Connected means Ethernet link is up and IP is obtained, otherwise, Disconnected is shown. MAC Address The MAC address used for device's WAN network interface.
IDU R2561 User Guide 3 Web Interface Click the "Refresh" button manual update the current status. Click the "Auto" button auto update the current status. 3.3.4 Status > About This page displays the device default necessary information. Those values are set by the manufacturer as the factory defaults. Figure 3‑ 7 About Product Name Product type. 2.4GHz Wi-Fi MAC 2.4GHz Wi-Fi MAC address 5GHz Wi-Fi MAC 5GHz Wi-Fi MAC address Model Name Device model name.
IDU R2561 User Guide 3 Web Interface 3.4 Menu Structure After entering "Detailed Configuration Page", the user can quickly jump to the specified Sub Menu. (By clicking "Quick Panel" at the bottom of the page.
IDU R2561 User Guide 3 Web Interface Advanced WPS Connected Client Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 4 Reference Manual 4 Reference Manual 4.1 Management 4.1.1 Management > Setup Wizard Figure 4‑ 1Setup Wizard Figure 4‑ 2 Setup Wizard - Set your Time Zone Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 4 Reference Manual Figure 4‑ 3 Setup Wizard - Configure Security and Network Name Figure 4‑ 4 Setup Wizard - Summary Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 4 Reference Manual The Setup Wizard will guide you to do the important setting of the device. Step 1 By press the "Next" button to start Wizard, we will guide you to set up your Time zone. Step 2 1. Selection your locate country, NTP server and location time zone, and check if your Location have daylight saving. 2. Review all your settings, if no problem, please press "Next". Step 3 Set up your 2.4GHz and 5GHz Wi-Fi network name/Encryption and Wi-Fi Password, then press "Next".
IDU R2561 User Guide 4 Reference Manual Figure 4‑ 5 WAN Setup - Dynamic IP Figure 4‑ 6 Set DNS Server Manually (Enable) Connection Mode Determine how Ethernet ports behave for network connection. Dynamic IP Mode One dedicated Ethernet port behaves as WAN connection via DHCP and the rest for LAN connection. Set DNS Server Manually : Use manually configured DNS server(s) for DNS query. Primary DNS Server : Primary DNS server for DNS query.
IDU R2561 User Guide 4 Reference Manual Figure 4‑ 7 LAN Setup - Disable Figure 4‑ 8 LAN Setup - Server Figure 4‑ 9 LAN Setup - Relay Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 4 Reference Manual LAN IP Address: Please input the LAN IP address here, the default value is 192.168.1.1 DHCP Service Type: Please select the DHCP service type, options are Disable, Server and Relay Disable: The device will not assign LAN IP address to PC; you have to manually set static IP address to the connected PC to access the UI.
IDU R2561 User Guide 4 Reference Manual DHCP Relay Server IP Address: The device will request IP address from the DHCP Relay server, please input the DHCP relay Server's IP address for obtain the IP address. If you input wrong DHCP Relay server IP address or Relay server is not working, please manually set static IP address to the connected PC to access the UI. Use the Add or Delete buttons to add or clear reserved IPs for leasing, please click Apply button to confirm the Add or Del.
IDU R2561 User Guide 4 Reference Manual Figure 4‑ 12 Telephony - Tone Setting Selection Figure 4‑ 13 Telephony - Call Feature Settings Figure 4‑ 14 Telephony - Speed Dial Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 4 Reference Manual Figure 4‑ 15 Telephony - Audio Enable VoIP This is a check box, please checked to enable the VoIP function or un-check to disable VoIP. Account User account Username The SIP (Session Initiation Protocol) User name. Its format depends on the SIP Server. − User Account The SIP Account. Its format depends on the SIP Server. − Password The SIP user Password. − Password Confirm Enter the SIP user Password again.
IDU R2561 User Guide 4 Reference Manual Enter the name that will be displayed as your ID/number, for the outgoing call the receiver will see your Display name as Caller ID (if supported by the SIP server). Server Account − User Domain This LTE Device's domain name. Registrar Address SIP server IPv4 address − − Outbound Proxy Address A SIP Outbound Proxy acts, like any proxy server.
IDU R2561 User Guide 4 Reference Manual or asterisk (*) to set continue on − Ring Back Tone Off Set ring back tone off for how long-in a ring tone cycle, please enter 0~10 seconds. Call Waiting Tone You can determine the call waiting tone sound here Frequency Quota: You can set the call waiting tone frequency here, the value should between 300~800 Hz.The device supports to set 1 or 2 frequency.
IDU R2561 User Guide 4 Reference Manual Enter a number of seconds after which the call waiting is timed out − Call Hold Enables or Disable the Call Hold function The Call Hold function is allow you to hold current call by press the flash key on the telephone − Dial Plan A dial plan is a set of rules used for determining whether a complete set of numbers has been entered for the IP address of SIP server.
IDU R2561 User Guide 4 Reference Manual 4.1.5 Management > Diagnostics This Diagnostics page will help you to perform a Ping or the Traceroute to troubleshoot the network connection. Figure 4‑ 16 Diagnostics - Ping Figure 4‑ 17 Diagnostics - Traceroute Diagnostic Tool Ping IP address/Domain Name: To issue a Test, please enter the destination IP address and Domain name here. − Ping Count: Please fill how many times the test need to be performed (Range: 1-50).
IDU R2561 User Guide 4 Reference Manual Example If the CPE fails to access the Internet, run the ping command to preliminarily identify the problem. To do so: 1. Choose Management > Diagnostics. On the Diagnosis Tools, set to Ping. The Ping page is displayed. 2. Enter the IP or domain name in the IP address/Domain Name field, for example, www.google.com. 3. Set Ping Count and Ping Packet Size. 4. Click Run 5. Wait until the ping command is executed. 6.
IDU R2561 User Guide 4 Reference Manual Log level There are four levels pre-defined: Critical/Error/Warning/Information, Please see below table. Scroll Auto: If you checked the Scroll Auto checkbox the syslog will always scroll to the bottom line to display the latest log If you just want to view the previously log, please un-checked it. Information Export: You can export your syslog out for the further analysis or issue tracking; the export format will be the .txt file with .tar compress.
IDU R2561 User Guide 4 Reference Manual Warning − Starts download firmware − Start upgrade firmware TR069 Connection Manager − SIM card is not inserted − VoIP − Failed to register to SIP − Failed to establish phone call − Failed to send register message to SIP server Wi-Fi − Client: unauthorized FOTA − Failed to connect to server − Error Verify PIN failed Failed to download Packages or firmware TR069 FOTA − Failed to upgrade firmware − Failed to verify firmware
IDU R2561 User Guide 4 Reference Manual Firmware upgrade fail Error Critical UNABLE to export System Log on IE8 browser 4.2 Personalization 4.2.1 Personalization > Configuration Figure 4‑ 19 Configuration Restore Factory Settings You can use Reset Factory Settings function to set device to factory default settings. When returning to factory defaults, it will reset all the parameters/settings you had ever done.
IDU R2561 User Guide 4 Reference Manual Export Configuration File You could export all of user settings in this device to a file. Import ConfigurationFile You could browse a configuration file and import it back. 1. UNABLE to export Configuration file on IE8 browser. 2. The imported config file name must be alphabet (A-Z or a-z), digit (0-9), minus sign (-) and underline(_). 3. The imported config file name extension must be ".tar". 4.2.
IDU R2561 User Guide 4 Reference Manual Password You can change the default Graphical User Interface (GUI) access password here. Password Maximum Length: Please define the password maximum length here in a range of 8~128. Old Login Password: Input the original /current login password. New Login Password: Enter a new log-in password you want to change, the new password total digits can't more than the value you set on the "Password Maximum Length" column.
IDU R2561 User Guide 4 Reference Manual 4.2.3 Personalization > Software Figure 4‑ 22 Software - Upgrade from file Upgrade From file: a. Click Browse button to select the IPK file. The IPK is the file with .ipkg, in each release you will get the ipk file release huawei-indoor-nomodem-unknown_V100R001C00SPCxxx_mips.ipk b. Click Install Software button to install the selected IPK file.
IDU R2561 User Guide 4 Reference Manual This page is to configure and change the firewall settings. The firewall feature can be used to block unauthorized access and allowing only authorized communications from the Internet network. It also allows the device to be managed over the Internet by authorized user. Figure 4‑ 23 Firewall Current Firewall Level Shows the current device firewall level.
IDU R2561 User Guide 4 Reference Manual Block Anonymous Internet Requests Select this check-box to reject anonymous Internet requests Filter Multicast Select this check-box to filter out multicast packets Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.3.2 Basic > DMZ For applications that require unrestricted access to the Internet, you can configure a specific client/server as a demilitarized zone (DMZ).
IDU R2561 User Guide 4 Reference Manual UPnP Enable UPnP IGD - Select this check-box to enable/disable Universal Plug and Play Internet Gateway Device - a protocol that simplifies device connection and network implementation. When this option is enabled, certain Windows applications would setup the port forwarding rule dynamically. Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.3.
IDU R2561 User Guide 4 Reference Manual Enable DDNS Select this check-box if the unit has a non-static IP address to keep the domain name associated with an ever-changing IP address. When DDNS is enabled, configure the following parameters: Server Address Username Password Domain Name Service Provider Select the DDNS service provider from the drop-down list. Click the Undo to clear the changes that you have made to this window. Clickthe Apply to activate your changes. 4.3.
IDU R2561 User Guide 4 Reference Manual Enable IPSecPassthrough Internet Protocol Security; IPSec provides encrypted security services at the IP layer, and enables to use encrypted tunnels/traffic between two hosts. Enable PPTP Passthrough Point to Point Tunneling Protocol; This protocol enables the transfer of data packets of TCP/IP through a foreign network that is not based on these protocols (by marking the packet with an address suited to the foreign network).
IDU R2561 User Guide 4 Reference Manual Current MAC filtering Status Shows the MAC filtering function is disable or enable. To enable or disable, you need to go to the Basic > Firewall level to change the firewall setting. Low: Filtering disable Medium: Filtering enable, you can set filtering by blacklist or whitelist on MAC filtering mode. High: Filtering enable, you can set filtering by blacklist or whitelist on MAC filtering mode.
IDU R2561 User Guide 4 Reference Manual 4.4.2 Advanced > IP Filtering You can block access to the Internet from clients on the local network by specifying IP addresses and TCP/UDP port numbers. You can configure up to five IP filters on the unit. In the IP Filter page you set IP addresses to be filtered out by the security system. You can add addresses to the filtered group or delete them. You can also enable or disable filtering at different times.
IDU R2561 User Guide 4 Reference Manual Enter the port range to be filtered. Protocol Set the protocol to be filtered: TCP or UDP. Enabled Select this check-box to enable or disable filtering for the specific table entry. Use the Add or Del buttons to add the rule to the group or clear it from the group, please click Apply button to confirm the Add or Del. Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.4.
IDU R2561 User Guide 4 Reference Manual LAN Port Enter the port number for LAN side. LAN IP Enter the IP address that identifies the IP subnet of the remote network. Enabled Select this check-box to enable/disable port forwarding for the specific IP. Use the Add or Del buttons to add the rule to the group or clear it from the group, please click Apply button to confirm the Add or Del. Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.4.
IDU R2561 User Guide 4 Reference Manual Enter a name for identifying this port trigger protocol. Protocol Set the protocol for port trigger: TCP, UDP or BOTH. Triggered Range Enter the trigger range (1~65535). Forwarded Range Enter the forwarded range (1~65535). Enabled Select this check-box to enable/disable port trigger for the specific application. Use the Add or Del buttons to add the rule to the group or clear it from the group, please click Apply button to confirm the Add or Del.
IDU R2561 User Guide 4 Reference Manual Use the Add or Del buttons to add the rule to the group or clear it from the group, please click Apply button to confirm the Add or Del. Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.4.6 Advanced > URL Filtering Figure 4‑ 33 URL Filtering Current URL filtering status Shows the URL filtering function is disable or enable.
IDU R2561 User Guide 4 Reference Manual Capital and Lower case letters, it matters to filtering) Use the Add or Del buttons to add the rule to the group or clear it from the group, please click Apply button to confirm the Add or Del. Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.4.
IDU R2561 User Guide 4 Reference Manual Select Select this check-box and press Del button to delete this row. Name Enter a name for identifying this ACL filter rule; it is free defining with 10 units' characters. Direction Define which direction for the filter LAN to Device LAN to WAN WAN to LAN WAN to Device Src IP Please define the start and end source IP address that the filter rule applies. Src Port Please fill in the source port number range.
IDU R2561 User Guide 4 Reference Manual ACCEPT Use the Add or Del buttons to add the rule to the group or clear it from the group, please click Apply button to confirm the Add or Del. Click the Undo to clear the changes that you have made to this window. Click the Apply to activate your changes. 4.4.8 Advanced > Parental Control Figure 4‑ 37 Parental Control Select Select this check-box and press Del button to delete this row.
IDU R2561 User Guide 4 Reference Manual 4.4.9 Advanced > Static Routing Figure 4‑ 38 Static Routing - Gateway mode Select Select this check-box and press Del button to delete this row. Destination IP Address Please fill-in the destination IP address for the route. Subnet Mask Please fill-in the subnet mask of the destination IP network. Gateway Please fill-in Gateway IP of the destination IP network.
IDU R2561 User Guide 4 Reference Manual 4.5 Wi-Fi 4.5.1 Wi-Fi > Basic Figure 4‑ 39 Wi-Fi - Basic -1 Figure 4‑ 40 Wi-Fi - Basic -2 Enable Wi-Fi Enables / disables the Wi-Fi radio 2.4GHz Wi-Fi Enable 2.4GHz Wi-Fi Enables / disables the 2.4GHz Wi-Fi radio. Network Name(SSID1/SSID2/SSID3/SSID4) The Service Set ID (SSID) that identifies the Wi-Fi network. The SSID is case sensitive and can consist of up to 32 alphanumeric characters. Following characters is valid for Network Name (SSID).
IDU R2561 User Guide 4 Reference Manual Hide SSID This function is to allow you to hide the SSID to prevent the unexpected connection request, please checked the checkbox to hide the SSID and unchecked it to broadcast the SSID. Encryption Data passing between the unit and clients must be protected from interception and eavesdropping. For a more secure network, the modem can implement one of several security mechanisms.
IDU R2561 User Guide 4 Reference Manual Hide SSID This function is to allow you to hide the SSID to prevent the unexpected connection request, please checked the checkbox to hide the SSID and unchecked it to broadcast the SSID. Encryption Data passing between the unit and clients must be protected from interception and eavesdropping. For a more secure network, the modem can implement one of several security mechanisms.
IDU R2561 User Guide 4 Reference Manual 4.5.2 Wi-Fi > Advanced Figure 4‑ 41 Wi-Fi - Advanced -1 Figure 4‑ 42 Wi-Fi - Advanced -2 2.4GHz Wi-Fi Working Mode It shows what Wi-Fi standard protocol is supported 802.11 b/g/n is supported. HT Mode The HT mode is channel bandwidth. You can select 20MHz or 20/40MHz to affect the performance on your network. Radio Channel The radio channel is used by the unit and its clients to communicate with each other.
IDU R2561 User Guide 4 Reference Manual your environment condition. Maximum connection number The maximum Wi-Fi clients can connect to device at the same time. AP Isolation When the AP isolation is set to OFF: All the connected Wi-Fi clients can ping each other.When the AP isolation is set to ON: The Wi-Fi clients can't ping each other ACL In this section you can add MAC addresses of clients which are allowed to access the system, or denied from accessing. 1.
IDU R2561 User Guide 4 Reference Manual 4.5.3 Wi-Fi > WPS Figure 4‑ 43 Wi-Fi - WPS 2.4GHz Wi-Fi 2.4G support NONE, WPA2 PSK + AES, WPA-WPA2-MIXED PSK + TKIP/AES. PBC User may connect multiple devices to the network and enable data encryption by pushing a button. Users should be aware that during the two-minute setup period which follows the push of the button, unintended devices could join the network if they are in range.
IDU R2561 User Guide 4 Reference Manual the available clients. PIN In Wi-Fi Protected Setup networks, a unique PIN (Personal Identification Number) will be required for each device to join the network. − PIN code: Another client would provide 4 or 8 PIN codes. Please insert the specific WPS client PIN code accordingly and the start icon would show up. − Start After input the PIN code then press the start, WPS will start and trying to connecting with the available clients. 4.5.
IDU R2561 User Guide 4 Reference Manual Click the "Refresh" button manual update the current status. 4.6 Engineering 4.6.1 How to Login Engineering page Step 1 Open the Web browser and enter the default IP address of the device, which is: 192.168.1.1 Figure 4‑ 45 Login page Step 2 Enter the advanced user login credentials to access web management interface. Default Log-in information: Username: admin Password: IDU@huawei Step 3 Click the Engineering menu.
IDU R2561 User Guide 4 Reference Manual 4.6.2 Engineering > DM Settings Figure 4‑ 47 DM Settings - TR069 Figure 4‑ 48 DM Settings - FOTA Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd.
IDU R2561 User Guide 4 Reference Manual DM switch Supporting DM You can multiple choose the DM for the device. DM WAN IP Display the current WAN IP TR069 Connection Status Display the current connection status: connected / dis-connected HTTP Authentication Algorithm SHA256 or MD5 ACS URL Enter the URL of the TR-069 ACS to establish the TR-069 session with ACS. ACS UserName Enter the user name for the authentication during connecting with ACS.
IDU R2561 User Guide 5 Federal Communication Commission 5 Federal Communication Commission 5.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
