Digital Fan Heater V 0DQXDO 2ZQHU Q English Model +)8 (
7$%/( 2) &217(176 9 2 81612-01 R20180601
,1752'8&7,21 Thank you for choosing the Hunter Fan Heater. This manual gives you complete instructions for using your heater. 6$)(7< $1' :$51,1*6 READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE! SAVE THESE INSTRUCTIONS FOR REFERENCE.
11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where openings may become blocked. 12. A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored. 13. Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, injury to persons, or other damage to property. 14.
3$576 2) 7+( +($7(5 1 2 Parts of the Heater Symbols 1. Control Panel Power Button 2. LED Display H/L Heat and Fan Button 3. Safety Grille Oscillation Button 4. Base High/Low Temperature Setting Button 3 4 Figure 1 Timer Button (Figure 1) (Figure 2) 23(5$7,1* ,16758&7,216 Operation 1. Place the heater on a firm, level surface, after assembling per this manual. Plastic or rubber tabs, like the feet on this unit, may stick to furniture surfaces and/or hardwood floors.
8. To turn the heater OFF, press the Power Button . The unit will first turn off the heating elements, the fan will be shut down 30 seconds later. Unplug the unit by pulling the plug from the electrical outlet only after the fan stopped. Oscillation Pressing the Oscillation Button will allow the heater to oscillate back and forth. To stop the oscillation, press the Oscillation Button again.
4. This function will cancel if the button is pressed. NOTE: It is normal for the heater "fan" to run for approximately 30 seconds when the heater shuts off after reaching the set temperature. 7,3 29(5 6:,7&+ This heater is equipped with a safety tip-over switch, which is located on the bottom of the heater. This feature cuts the main power to the heater if it gets knocked over. If the heater does tip over, simply stand it upright in order to resume operation.
STORAGE 1. Perform the cleaning procedures described above. 2. Wipe all parts dry. 3. Pack the heater in a plastic bag and store it in a cool, dry place. We recommend that you store the heater in its original carton. TROUBLE SHOOTING If your heater fails to operate: Make sure the electrical outlet or circuit breaker is working. Check for obstructions. If you find an obstruction, turn the heater OFF, and UNPLUG THE UNIT. Carefully remove the obstruction and follow the reset instructions.
WARRANTY Hunter Home Comfort makes the following limited warranty to the user or consumer purchaser of this Hunter heater: If your Hunter heater motor fails at any time within three years after the date of sale to you due to a defect in material or workmanship, labor to repair the defect will be provided free of charge at our nearest service center or our Service Department in Marietta, Georgia. You will be responsible for labor costs after this three years period.
shipping your heater to us. If we authorize you to ship it to us, you will be responsible for all insurance and freight or other transportation charges to our factory service center. We will return your Hunter heater freight prepaid. Your heater should be properly packed to avoid damage in transit since we will not be responsible for any such damage. Proof of purchase is required when requesting warranty service. The purchaser must present sales receipt or other document that establishes proof of purchase.
