HURTSGR - HURTSPK - HURTSCA HURTSWH - HURTSBU - HURTSRD Lightweight and Foldable Kick Scooter Adjustable Scooter for Teens and Adult, Alloy Deck with High Impact Wheels
CONTENT SAFETY WARNINGS 2 BEFORE YOU BEGIN 5 ASSEMBLY INSTRUCTIONS 6 SETUP AND USAGE INSTRUCTIONS 7 CHECK BEFORE RIDING 9 SAFETY REMINDERS 10 LIMITED WARRANTY 11 FEATURES & TECHNICAL SPECS 12 SAFETY WARNINGS AN IMPORTANT MESSAGE TO PARENTS: This manual contains important information. For your child’s safety, it is your responsibility to review this information with your child and make sure that your child understands all warnings, cautions, instructions and safety topics.
GENERAL WARNING Scooter riding can be a hazardous activity. Scooters can and are intended to move and it is therefore possible to get into dangerous situations and/or lose control and/or fall. If such things occur you can be seriously injured or die. Like any other moving product, using a scooter can be a dangerous activity and may result in injury or death even when used with proper safety precautions. Use at your own risk and use common sense.
• Do not allow children under 8 to use the scooter. Children under 9 should ride with adult supervision at all times. All children and preteens should ride with adult guidance at all times. • Rider weight doesn’t necessarily mean a child’s size is appropriate to fit or maintain control of scooter. • Aparent’s decision to allow his or her child to ride this product should be based on the child’s maturity, skill and ability. • Refer to the section on safety for additional warnings.
PROPER RIDING ATTIRE Always ensure child is wearing proper protective equipment such as an approved safety helmet. A helmet may be legally required by local law or regulation in your area. A child should always wear shoes, never ride barefooted or in sandals, and keep shoelaces ties and out of the way of the wheels. FAILURE TO USE COMMON SENSE AND HEED ABOVE WARNINGS FURTHER INCREASES RISK OF SERIOUS INJURY. USE AT YOUR OWN RISK AND WITH APPROPRIATE AND SERIOUS ATTENTION TO SAFE OPERATION. USE CAUTION.
ASSEMBLY INSTRUCTIONS Handlebar T-tube Steering Column Collar Clamp Clamp Grips Steering Tube Quick-Release Lock/Release Folding Mechanism Brake Front Fork Deck Wheels 6 www.PyleUSA.
SETUP AND USAGE INSTRUCTIONS 1 To adjust the height of the handlebars, unlock the steering tube by pulling outward on the quick-release lever. Slide the T-tube to the desired position and secure bypushing inward on the quickrelease lever. 2 The tension of the quick release clamping mechanism can be adjusted by tightening or loosening the Allen bolt. Be careful not to over tighten.
3 4 To unfold the scooter, pull the release lever downwards toward the deck while pulling upwards on the steering column. 5 To fold the scooter push the handlebars forward lightly while pulling back on the release lever. if may help if you place one foot on the deck. When the release lever unlatches, pull back on the handlebars and continue folding your scooter until it latches. 8 www.PyleUSA.com Release the lever and continue to unfold the steering column upward.
WARNINGS DO NOT USE NON-HURTLE RENEGADE PRODUCTS WITH YOUR SCOOTER. HURTLE RENEGADE scooters have been built to certain design specifications. The original equipment supplied at the time of sale was selected on the basis of its compatibility with the frame, fork and all other parts. Certain after market products may or may not be compatible. Failure to properly engage the quick-release clamps may cause the T-Bar to telescope up or down while riding, which may cause youto lose control and fall.
WHEELS AND BEARINGS Under normal circumstances and conditions, street surfing wheels and wheel bearings are maintenance free. nonetheless, it is the responsibility of the owner or guardian to periodically inspect the wheel for wear and tear, the axle for proper tightness, and bearing for side-to-side play and loose parts. When a wheel or wheel bearing develops play, this is an indication of excess wear and replacement is necessary. Replace immediately with only genuine street surfing wheels.
HOW TO RIDE Place one foot on the deck, push forward with the other foot. steer. For enhanced cornering, lean slightly into the direction of the turn. For controlled stops, apply the brake by stepping on the rear fender/brake. Practice applying the brake at various speeds and in an open area free from obstructions before riding around others. BE CAREFUL! You will see people on TV and maybe even people you know doing tricks and stunts.
The manufacturer warranties this product to be free of manufacturing defects for a period of 6 months from date of purchase. This limited Warranty does not cover normal wear and tear, tires, tubes or cables, or any damage, failure or loss caused by improper assembly, maintenance, or storage. This limited Warranty will be void if product is ever: • Used in a manner other than for recreation. • Modified in any way. • Rented.
• Long-Lasting, Super Smooth Gliding Wheels • Easy Maneuvering Lean-to-Steer Technology • Lab Tested & Safety Certified • Indoor/Outdoor Use • Suitable for Teenagers and Adult, Beginner and Intermediate Riders • Long Guard Rail to Stop Easily • Mud Guard Front Wheel • Extended up to 3 Heights • Easy Folding Technology • Foldable Handles • Non-Slip Deck + Foot Stand • Front Suspension Technical Specs: • Construction Material: 20% Steel + 80% Alloy • Wheel Type / Wheel Material: PU Wheel • Recommended Age: 8+
HURTSBU HURTSPK HURTSWH HURTSRD HURTSGR HURTSCA
