Owner's Manual

GUARD REPLACEMENT INSTRUCTIONS
NOZZLE GUARD
Model #6951
1. Turn off dispenser and relieve the
line pressure.
2. Remove nozzle from hose.
3. Remove old nozzle guard.
4. Install new guard over spout and
pull back to cover nozzle body.
5. Reinstall nozzle to hose.
6. Test nozzle for automatic shut off.
NOZZLE REGUARD
Model #4231
1. Cut old nozzle guard at nozzle
inlet and remove from nozzle.
2. Install new nozzle reguard over
spout and pull back to cover
nozzle body.
3. Pull tie through the eyelets and
loop under nozzle inlet.
4. Pull tightly and trim off excess tie.
LEVER COVER
Model #5494
1. Remove old lever cover.
2. Snap new lever cover into place.
POPD™ GUARD
Model #6660
1. Turn off dispenser and relieve the
line pressure.
2. Remove nozzle from hose.
3. Remove old guard.
4. Install new POPD™ guard over
spout and pull back to cover
nozzle body.
5. Reinstall nozzle to hose.
6. Test nozzle for automatic shut off.
7. Install desired advertisement and
clear cover (model #6628).
POPD™ REGUARD
Model #7220
1. Cut old nozzle guard at nozzle
inlet and remove from nozzle.
2. Install new POPD™ guard over
spout and pull back to cover
nozzle body.
3. Pull tie through the eyelets and
loop under nozzle inlet.
4. Pull tightly and trim off excess tie.
5. Install desired advertisement and
clear cover (model #6628).
POPD™ CLEAR COVER
Model #6628
1. Trim advertisement to 3.75 in /
95.25 mm x 3.75 in / 95.25 mm.
2. Notch corners of advertisement
approximately .375 in / 9.5 mm x
.375 in / 9.5 mm.
3. Turn clear cover "inside-out".
4. Center advertisement on POPD™
guard, using the notched corners
as guides, and fold over edges.
5. Lay clear cover over
advertisement, making sure the
advertisement stays centered,
and turn it "right-side out".
6. Conrm the cover is securely in
place.
Husky Corporation • 2325 Husky Way • Pacic, MO 63069 • Phone: [phone] • Fax: [phone] • www.husky.com
Page 4 009218-6 9/2011
HOLD OPEN CLIP INSTALLATION / REMOVAL INSTRUCTIONS
Model #3593 Hold Open Clip Kit
INSTALLATION
1. Remove nozzle from hose and drain.
2. Position latch spring under latch clip and hose
them in place. The latch clip should straddle the
mating holes in the trigger lever.
3. Insert latch rivet through latch clip and lever,
making sure latch spring is secured in position
by the rivet.
4. Install push nut on rivet - DO NOT hammer in
place.
5. Squeeze lever several times to check
operation.
6. Verify clip and lever are parallel.
NOTE: Field installation of the hold open clip is NOT UL approved because
improper installation may cause the nozzle to fail.
REMOVAL
1. Remove nozzle from hose and drain.
2. Place nozzle on a at surface in safe location.
3. Hold up on the latch clip to prevent rivet from
rotating.
4. Drill off the riveted end using a ¼" / 6.4 mm bit.
5. Do not remove latch plate.
NOTE: Nozzles can be ordered without clips.
ACCESSORIES
Model #0397 - Unlead spout gauge
FLO-EQUALIZER™ INSTALLATION INSTRUCTIONS
Model #5837 Vacuum-Assist Flo-Equalizer™
1. Turn off dispenser and relieve line pressure.
2. Lubricate the o-rings.
3. DO NOT use Teon tape.
4. Tighten rmly, approximately 15 - 20 lbf•ft / 20.3 - 27.1 N•m, but do not overtighten.
5. Conrm nozzle is properly installed, pressurize the system and check for leaks.
NOTE: In the event of pressure differential in excess of 25 psi / 1.7 bar across the Flo-Equalizer™ or the presence of debris obstructing movement of internal
components, the Flo-Equalizer™ output may exceed 10 gpm / 37.9 Lpm.
