Hustler® Raptor SD

200 South Ridge Road

Hesston, Kansas

67062

Hustler

Raptor SD

48", 54" & 60"

Parts Manual

Summary of content (78 pages)

PAGE 1
Hustler® Raptor SD 48", 54" & 60" Parts Manual ® 200 South Ridge Road Hesston, Kansas 67062
PAGE 2
WARNING The engine exhaust from this product contains chemicals known to the state of California to cause cancer, birth defects or other reproductive harm. NOTICE OF REQUIREMENT OF SPARK ARRESTER MUFFLER This equipment may create sparks that can start fires around dry vegetation. California Public Resources Code Section 4442.
PAGE 3
Table of Contents General Information Service Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Options Available From Your Dealer. . . . . . . . . . . . . . . . . . . . . . . . Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Standard Torques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1-1 1-1 1-2 Section 2 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 4
c-2 118791_1113
PAGE 5
General Information This manual covers Raptor® SD models 932541, 932558 & 932566. Service Literature PART NO. 604856 118649 118650 DESCRIPTION OPERATOR’S MANUAL WARRANTY STATEMENT SERVICE MANUAL Options Available From Your Dealer PART NO. 119101 119060 119091 117682 333724 932525 DESCRIPTION 48” MULCH KIT 54” MULCH KIT 60” MULCH KIT LIGHT KIT STEERING LEVER EXTENSION 2-BAG CATCHER KIT Note: When ordering parts, you must use the part number as shown for each part, not the index number.
PAGE 6
Hardware Description Codes & Abbreviations The following codes are used throughout this parts manual. Refer to this list when ordering parts.
PAGE 7
Section 2 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2 Fenders & Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4 Engine Guard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 8
Frame 1 3 2 4 5 4 3 12 6 7 8 12 13 9 10 4 14 11 9 17 4 9 18 9 16 18 15 3 3 9 3 15 3 9 3 20 13 21 19 3 22 23 21 1 3 9 24 25 3 3 9 9 12 3 27 3 27 9 28 12 26 16 27 26 9 21 2 29 9 26 2-2 118791_1113
PAGE 9
Frame INDEX NO. PART NO. QTY. DESCRIPTION 1 118539 1 SEAT SUPPORT 2 118538 1 SPRING SUPPORT 3 029629 10 CS .375-16 X .75 HX FLK 4 604176 30 CS .375-16 X .75 HX FLK PLN 5 117787 1 RS REAR BRACKET 6 602041 1 HOT DECAL 7 552217 1 BUMPER (WITH DECAL) 8 551858 1 ENGINE PLATE (WITH DECALS) 9 604177 30 NT .375-16 HX FLK PLN 10 601967 1 ENGINE COMPARTMENT DECAL 11 117788 1 LS REAR BRACKET 12 601982 5 CN .250-20 X .
PAGE 10
Fenders & Instrument Panel 1 21 2 3 4 7 8 5 6 9 7 10 13 12 11 13 13 14 13 16 17 15 18 19 20 22 2-4 118791_1113
PAGE 11
Fenders & Instrument Panel INDEX NO. PART NO. QTY. DESCRIPTION 1 601097 1 CHOKE CABLE 2 776476 1 PTO SWITCH 3 769166 1 HOUR METER 4 785808 1 KEY ASSEMBLY 5 552300 1 INSTRUMENT PANEL (WITH DECAL) 6 604889 1 INSTRUMENT PANEL DECAL 7 045898 1 IGNITION SWITCH 8 055939 1 CS .250-20 X .75 HX G5 9 601098 2 CB 10-24 X .500 ZYNC 10 704932 2 FW .219 X .500 X .048 ZNYC 11 059832 2 NT #10-24 HX NL ZN 12 601096 1 THROTTLE CABLE 13 604324 8 CS .250-20 X .
PAGE 12
Engine Guard 1 2 4 3 2-6 118791_1113
PAGE 13
Engine Guard INDEX NO. PART NO. QTY. DESCRIPTION 1 118987 1 ENGINE GUARD 2 604745 1 H LOGO DECAL 3 029629 4 CS .375-16 X .75 HX FLK 4 016899 4 NT .
PAGE 14
Battery 2 1 3 4 5 7 6 8 6 5 BATTERY 9 2-8 118791_1113
PAGE 15
Battery INDEX NO. PART NO. QTY. DESCRIPTION 1 604178 1 TIE DOWN STRAP 2 604465 2 CS 0.250-20 X 7.50 HX G5 3 768515 2 FW .281 X .625 X .051/.080 HD ZN/YL 4 771428 1 RED BATTERY CABLE BOOT 5 024927 2 NT .250-20 HX G5 ZNYC 6 029868 4 LW .250 INT-EXT TOOTH Z 7 055939 2 CS .250-20 X .75 HX G5 8 000331 2 WIRE TIE 9 601982 2 CN .250-20 X .15 MAX THK NOTES: 1.
PAGE 16
2-10 118791_1113
PAGE 17
Section 3 Hydraulic System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 Transmission Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6 Transmission Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 Steering & Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10 Steering Cover Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 18
Hydraulic System 1 18 18 2 3 18 4 19 1 18 3 18 5 10 11 6 12 7 4 13 14 15 8 16 9 17 11 16 13 17 TRANSMISSION ASSEMBLY 18 18 1 18 19 1 19 1 3-2 118791_1113
PAGE 19
Hydraulic System INDEX NO. PART NO. QTY. DESCRIPTION 1 710087 4 CS .312-18 X 2.50 HX G5 2 601887 1 CB .375-16 X 2.75 STD ZN 3 043067 4 CS .312-18 X 3.00 HX G5 Z 4 016899 3 NT .375-16 HX FLK ZNYC 5 603907 1 DRIVE BELT 6 604714 1 IDLER SPACER 7 116287 1 IDLER ARM 8 712893 1 FW .406 X 1.25 X .12 HRD Z 9 086660 1 NT .375-16 NL G5 10 080655 1 CS .375-16 X 1.50 HX G5 11 767954 2 FW .406 X .812 X .060 SAE 12 604491 1 PULLEY 2.0" IDLER 13 054502 2 NT .
PAGE 20
Hydraulic System 22 20 21 26 23 21 24 25 4 TRANSMISSION ASSEMBLY 3-4 118791_1113
PAGE 21
Hydraulic System INDEX NO. PART NO. QTY DESCRIPTION 20 068551 2 NT .250-20 HX ZY NL 21 768515 4 FW .281 X .625 X .051/.080 HD ZN/YL 22 118284 1 EXPANSION TANK MOUNT 23 601996 1 OVERFLOW TANK 24 055939 2 CS .250-20 X .75 HX G5 25 029629 1 CS .375-16 X .
PAGE 22
Transmission Assembly 2 3 2 1 2 4 5 LEFT SIDE SHOWN RIGHT SIDE SIMILAR 6 7 6 17 16 8 18 15 10 BRAKE ARM BRAKE CLIP 10 9 10 9 13 9 9 8 12 11 A 11 B FRONT OF MOWER 14 3-6 118791_1113
PAGE 23
Transmission Assembly INDEX NO. PART NO. QTY. DESCRIPTION 1 058776 2 NT .312-18 HX NL G5 2 768523 6 FW .343 X .687 X .051/.080H 3 601051 2 OVERTRAVEL SPRING 4 601131 2 SPRING 5 604667 2 ROD BRAKE ACTUATOR 6 601219 2 FITTING, 90 - 9/16 SAE 7 604709 1 LS TRANSMISSION 8 056036 2 CS .375-16 X 2.25 HX G5 9 767954 4 FW .406 X .812 X .060 SAE 10 601001 4 SPRING CLAMP 11 787713 47" 12 000331 2 WIRE TIE 13 086660 2 NT .
PAGE 24
Transmission Service Parts 1 3 2 7 8 6 5 4 3-8 118791_1113
PAGE 25
Transmission Service Parts 604708 RIGHT SIDE TRANSMISSION INDEX NO. PART NO. QTY. DESCRIPTION 1 604901 1 HG RTN CW 2 604903 1 HG RTN SPRING 3 602094 1 FAN/PULLEY KIT 4 600975 1 LS FILTER GUARD (WITH HARDWARE) 5 600976 1 OIL FILTER 6 600970 1 4 BOLT HUB KIT (WITH HUB NUT) 7 601221 1 BRAKE ARM 8 600972 1 RETAINING CLIP 604709 LEFT SIDE TRANSMISSION INDEX NO. PART NO. QTY.
PAGE 26
Steering & Brake 2 1 3 4 FRONT OF MOWER 10 12 1 11 5 16 7 6 8 14 9 LEFT SIDE SHOWN; 13 RIGHT SIDE SIMILAR 8 19 8 9 15 14 2 21 3 16 20 3 17 18 16 17 FRONT OF MOWER 3-10 118791_1113
PAGE 27
Steering & Brake INDEX NO. PART NO. QTY. DESCRIPTION 1 603983 2 DAMPER 2 781922 4 BALL STUD 3 768523 6 FW .343 X .687 X .051/.080H 4 058776 2 NT .312-18 HX ZY NL 5 601069 2 CN .312-18 X .20 MAX THK 6 772483 2 SB .312 X .75 SH .250-20 7 604173 2 YOKE, 5/16-24 8 041152 6 NT .312-24 HX ZNYC 9 604666 2 STEERING ROD 10 768515 2 FW .281 X .625 X .051/.080 HD ZN/YL 11 068551 2 NT .
PAGE 28
Steering Cover Assembly 1 1 2 2 4 3 6 4 2 5 4 7 5 12 10 2 3 4 8 9 13 11 14 16 18 19 14 13 20 15 13 16 6 7 17 21 8 10 23 23 14 11 16 18 19 13 14 13 20 22 13 15 16 3-12 118791_1113
PAGE 29
Steering Cover Assembly INDEX NO. PART NO. QTY. DESCRIPTION 1 604452 2 CS .250-20 X 2.00 HX FLTHD 2 768515 4 FW .281 X .625 X .051/.080 HD ZN/YL 3 117540 2 DRIVE STRAIGHT STOP 4 808477 4 1/4-20 THREAD RIVET NUT 5 055939 2 CS .250-20 X .75 HX G5 6 601822 2 NUT PLATE .420 CENTERS 7 781211 2 PUSH BUTTON SWITCH 8 086660 3 NT .375-16 HX ZY NL 9 552415 1 STEERING COVER (WITH DECALS) 10 781708 2 CS .500-13 X 4.
PAGE 30
Steering Cover Assembly 24 25 26 24 28 8 32 29 27 33 27 35 31 34 30 3-14 118791_1113
PAGE 31
Steering Cover Assembly INDEX NO. PART NO. QTY. DESCRIPTION 24 769257 4 FW .656 X 1.25 X .250 ZNY 25 604793 1 BUSHING 26 118479 1 TRANSPORT LATCH 27 767954 2 FW .406 X .812 X .060 SAE 28 029629 1 CS .375-16 X .75 HX FLK 29 552177 1 INDICATOR (WITH DECAL) 30 604819 1 DECK HEIGHT DECAL 31 056036 1 CS .375-16 X 2.25 HX G5 32 016899 1 NT .
PAGE 32
3-16 118791_1113
PAGE 33
Section 4 Wheel & Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2 Front Tire Breakdown—Smooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4 Drive Wheel Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 34
Wheel & Tire 3 4 5 6 2 7 1 1 6 8 4-2 118791_1113
PAGE 35
Wheel & Tire INDEX NO. PART NO. QTY. DESCRIPTION 2 TIRE/WHEEL 20 X 8-10 (48" MOWER) 601349 2 TIRE/WHEEL, 20 X 12-10 (54"/60" MOWER) 2 061077 8 WHEEL NUT 3 705954 2 CS .500-13 X 1.25 HX G5 ZN 4 344267 2 FW .510 X 2.15 X .187 SPL 5 712976 2 FW .531 X 1.375 X .125 ZNY 6 784223 4 BEARING 7 784603 2 SPACER 8 N/A 1 TIRE/WHEEL ASSEMBLY 1 600676 NOTES: 1. Torque to 65–75 ft-lbs.
PAGE 36
Front Tire Breakdown—Smooth 6 8 7 7 9 1 2 3 3 4 5 4-4 118791_1113
PAGE 37
Front Tire Breakdown—Smooth INDEX NO. PART NO. QTY DESCRIPTION 1 604691 1 FORK 2 041475 1 CS .750-10 X 9.50 HX ZY 3 025296 2 FW .760 X 1.625 X .08 ZNYC 4 061101 1 NT .750-10 HX ZY NL 5 604717 1 TIRE/WHEEL 6 604843 1 TIRE, 13 X 6.50-6 SMOOTH 7 604845 2 WHEEL BEARING 8 604844 1 WHEEL, 6 X 4.
PAGE 38
Drive Wheel Breakdown 1 2 3 600676 TIRE/WHEEL ASSEMBLY (48" DECKS) INDEX NO. PART NO. QTY. DESCRIPTION 1 600692 1 TIRE 20 X 8-10 2 600718 1 WHEEL 3 019521 1 TIRE VALVE 601349 TIRE/WHEEL ASSEMBLY (54" & 60" DECKS) 1 601348 1 TIRE 20 X 12-10 2 601347 1 WHEEL 10 X 8.
PAGE 39
Section 5 Engine, Kawasaki FR651V/FR691V/FR730V . . . . . . . . . . . . . . . . . . 5-2 Engine Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6 Fuel System—Without Carbon Canister . . . . . . . . . . . . . . . . . . . . . . 5-8 Fuel Tank Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 40
Engine, Kawasaki FR651V/FR691V/FR730V 1 2 4 3 1 5 11 6 12 16 13 14 15 2 7 8 3 8 10 9 5-2 118791_1113
PAGE 41
Engine, Kawasaki FR651V/FR691V/FR730V INDEX NO. PART NO. QTY. DESCRIPTION 1 N/A 1 KAWASAKI FR651V/FR691V/FR730V ENGINE 2 604369 1 O-RING 3 604350 1 OIL DRAIN VALVE 4 604463 12" OIL DRAIN HOSE 5 604016 1 MUFFLER 6 016899 1 NT .375-16 HX FLK ZNYC 7 118238 1 CLUTCH ANCHOR 8 767954 5 FW .406 X .812 X .060 SAE 9 036244 1 CS .375-16 X 1.00 HX G5 10 602580 4 CS .375-16 X 1.
PAGE 42
Engine, Kawasaki FR651V/FR691V/FR730V 17 18 BLK 5 RED 5 19 5 18 20 22 23 21 5 BLK 1 5 RED 15A FUSE 5 5 24 11 24 A 25 4 26 11 5-4 118791_1113
PAGE 43
Engine, Kawasaki FR651V/FR691V/FR730V INDEX NO. PART NO. QTY. DESCRIPTION 17 055939 2 CS .250-20 X .75 HX G5 18 768515 4 FW .281 X .625 X .051/.080 HD ZN/YL 19 044255 1 NT #10-32 HX ZN 20 030817 1 STARTER SOLENOID 21 024927 2 NT .250-20 HX G5 ZNYC 22 029876 1 LW .312 INT-EXT TOOTH 23 720516 1 CS M8 X 1.25 X 16 HX G10.
PAGE 44
Engine Service Parts 1 2 3 INDEX NO. PART NO. QTY.
PAGE 45
This page intentionally left blank.
PAGE 46
Fuel System—Without Carbon Canister 4 3 6 7 3 A 5 2 8 9 6 7 10 4 6 7 11 12 1 13 15 B C 15 14 14 B 15 5-8 118791_1113
PAGE 47
Fuel System—Without Carbon Canister INDEX NO. PART NO. QTY. DESCRIPTION 1 604336 1 FUEL TANK ASSEMBLY 2 603807 1 RATCHETING GAS CAP, 3.5" 3 117059 1 LEFT TANK MOUNT 4 117060 1 RIGHT TANK MOUNT 5 713198 18.5" 6 055939 3 CS .250-20 X .75 HX G5 7 768515 3 FW .281 X .625 X .051/.
PAGE 48
Fuel Tank Service Parts 1 3 2 4 1 2 INDEX NO. PART NO. QTY. DESCRIPTION 1 604199 2 VENT FITTING 2 604200 2 GROMMET 3 604340 1 SUCTION HOSE ASSEMBLY 7.
PAGE 49
Section 6 48" Service Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2 48" Deck Pulleys & Spindles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4 48" Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6 54" Service Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8 54" Deck Pulleys & Spindles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 50
48" Service Deck 2 1 3 5 4 INDEX NO. PART NO. QTY.
PAGE 51
This page intentionally left blank.
PAGE 52
48" Deck Pulleys & Spindles 1 1 2 3 4 6 7 5 6 1 8 9 11 12 10 13 1 14 15 1 2 17 13 16 18 22 19 16 2 21 20 6-4 118791_1113
PAGE 53
48" Deck Pulleys & Spindles INDEX NO. PART NO. QTY. DESCRIPTION 1 781567 3 NT .500-13 NL G5 2 767962 3 FW .531 X 1.063 X .090 SAE 3 603986 1 IDLER PULLEY, 4.00" FLAT 4 604251 4 NT .312-18 HX NL JAM G2 ZN 5 604252 4 FW .340 X .675 X .035 ZN 6 604110 2 SPRING TENSIONER ANCHOR 7 604291 1 IDLER SPRING 8 604194 1 IDLER SLED 9 604079 2 IDLER SLIDE 10 604253 1 CB .50-13 X 2.00 STD ZN 11 705954 3 CS .500-13 X 1.25 HX G5 ZN 12 798603 3 FW .515 X 1.65 X .
PAGE 54
48" Deck 1 2 5 3 2 4 8 6 7 9 10 11 12 13 9 14 14 18 15 19 21 19 16 20 17 1 6-6 118791_1113
PAGE 55
48" Deck INDEX NO. PART NO. QTY. DESCRIPTION 1 604337 1 RS PULLEY COVER 2 604324 4 CS .250-20 X .75 HX FLG 3 604830 1 BELT, B-SECTION 4 604338 1 LS PULLEY COVER 5 604609 1 DISCHARGE CHUTE 6 604346 1 DISCHARGE CHUTE PIN 7 604331 1 CHUTE SPRING 8 086660 1 NT .375-16 NL G5 9 604658 2 PULLER PIN 10 117877 1 RS PULLER 11 117878 1 LS PULLER 12 781567 3 NT .500-13 NL G5 13 767962 3 FW .531 X 1.063 X .
PAGE 56
54" Service Deck 2 1 3 5 4 INDEX NO. PART NO. QTY.
PAGE 57
This page intentionally left blank.
PAGE 58
54" Deck Pulleys & Spindles 1 1 2 3 4 6 7 5 6 8 9 11 12 14 10 1 13 1 2 15 13 16 17 4 22 19 16 2 18 20 6-10 21 118791_1113
PAGE 59
54" Deck Pulleys & Spindles INDEX NO. PART NO. QTY. DESCRIPTION 1 781567 3 NT .500-13 NL G5 2 767962 3 FW .531 X 1.063 X .090 SAE 3 604792 1 IDLER PULLEY, 5.00" O.D. 4 604251 7 NT .312-18 HX NL JAM G2 ZN 5 604252 6 FW .340 X .675 X .035 ZN 6 604110 2 SPRING TENSIONER ANCHOR 7 604291 1 IDLER SPRING 8 604791 1 IDLER SLED 9 604790 2 IDLER SLIDE 10 604253 1 CB .50-13 X 2.00 STD ZN 11 705954 3 CS .500-13 X 1.25 HX G5 ZN 12 798603 3 FW .515 X 1.65 X .
PAGE 60
54" Deck 1 2 3 5 2 4 8 6 7 9 10 18 11 12 13 18 9 14 14 19 20 15 22 20 21 16 17 1 6-12 118791_1113
PAGE 61
54" Deck INDEX NO. PART NO. QTY. DESCRIPTION 1 604722 1 RS PULLEY COVER 2 604324 4 CS .250-20 X .75 HX FLG 3 604817 1 BELT, B-SECTION 4 604723 1 LS PULLEY COVER 5 604609 1 DISCHARGE CHUTE 6 604346 1 DISCHARGE CHUTE PIN 7 604331 1 CHUTE SPRING 8 086660 1 NT .375-16 NL G5 9 604658 2 PULLER PIN 10 117877 1 RS PULLER 11 117878 1 LS PULLER 12 781567 3 NT .500-13 NL G5 13 767962 3 FW .531 X 1.063 X .
PAGE 62
60" Service Deck 5 1 4 2 3 INDEX NO. PART NO. QTY.
PAGE 63
This page intentionally left blank.
PAGE 64
60" Deck Pulleys & Spindles 1 1 2 3 6 4 5 7 8 6 9 1 11 1 12 15 2 14 10 13 1 13 17 16 4 22 19 16 20 2 21 18 6-16 118791_1113
PAGE 65
60" Deck Pulleys & Spindles INDEX NO. PART NO. QTY. DESCRIPTION 1 781567 3 NT .500-13 NL G5 2 767962 3 FW .531 X 1.063 X .090 SAE 3 604792 1 IDLER PULLEY, 5.00" O.D. 4 604251 7 NT .312-18 HX NL JAM G2 ZN 5 604252 6 FW .340 X .675 X .035 ZN 6 604110 2 SPRING TENSIONER ANCHOR 7 604291 1 IDLER SPRING 8 604791 1 IDLER SLED 9 604790 2 IDLER SLIDE 10 604253 1 CB .50-13 X 2.00 STD ZN 11 705954 3 CS .500-13 X 1.25 HX G5 ZN 12 798603 3 FW .515 X 1.65 X .
PAGE 66
60" Deck 1 2 3 2 5 4 8 6 7 9 10 18 11 12 18 13 9 14 14 15 19 20 22 20 16 21 17 1 6-18 118791_1113
PAGE 67
60" Deck INDEX NO. PART NO. QTY. DESCRIPTION 1 604722 1 RS PULLEY COVER 2 604324 4 CS .250-20 X .75 HX FLG 3 604711 1 BELT, B-SECTION 4 604723 1 LS PULLEY COVER 5 604609 1 DISCHARGE CHUTE 6 604346 1 DISCHARGE CHUTE PIN 7 604331 1 CHUTE SPRING 8 086660 1 NT .375-16 NL G5 9 604658 2 PULLER PIN 10 117877 1 RS PULLER 11 117878 1 LS PULLER 12 781567 3 NT .500-13 NL G5 13 767962 3 FW .531 X 1.063 X .
PAGE 68
Deck Lift—Right Side 1 4 3 5 7 9 8 6 2 5 5 10 5 14 6 11 12 4 16 15 9 20 19 2 17 5 18 5 13 10 11 13 14 12 15 19 21 6-20 118791_1113
PAGE 69
Deck Lift—Right Side INDEX NO. PART NO. QTY. DESCRIPTION 1 118020 1 INDICATOR PIN 2 016899 8 NT .375-16 HX FLK ZNYC 3 118085 1 REAR DECK LIFT BAR 4 054502 2 NT .375-16 HX G5 ZNY 5 767954 8 FW .406 X .812 X .060 SAE 6 601839 2 PIVOT SPACER BUSHING 7 118016 1 LIFT PEDAL LINK 8 052860 1 CS .375-16 X 1.25 HX G5 9 086660 4 NT .375-16 NL G5 10 605114 4 FW .41 X .94 X .25 UHMW 11 118018 4 PIVOT 12 604579 4 DECK LIFT LINK 13 604803 4 CE .375 X 2.
PAGE 70
Deck Lift—Left Side 9 3 5 10 9 17 2 11 5 14 10 15 12 13 11 2 14 15 6-22 12 13 118791_1113
PAGE 71
Section 7 Seat, Standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2 Seat Service Parts, Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4 Seat, Removable Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6 Seat Service Parts, Removable Back . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 72
Seat, Standard 1 3 2 6 7 1 4 2 8 5 12 9 11 10 11 7-2 118791_1113
PAGE 73
Seat, Standard INDEX NO. PART NO. QTY. DESCRIPTION 1 792226 1 STANDARD SEAT 2 551897 1 SEAT PAN (WITH DECAL) 3 604307 1 PUSH BUTTON MOUNT 4 086660 2 NT .375-16 NL G5 5 000331 1 WIRE TIE 6 768523 4 FW .343 X .687 X .051/.080H 7 079186 4 CS .312-18 X 1.25 HX G5 8 029629 3 CS .375-16 X .75 HX FLK 9 793851 3 COMPRESSION SPRING 1.25 X 4.00 X .188 10 016899 3 NT .375-16 HX FLK ZNYC 11 036244 2 CS .375-16 X 1.00 HX G5 12 601815 1 BATTERY WARNINGS DECAL NOTES: 1.
PAGE 74
Seat Service Parts, Standard 1 3 2 4 5 6 7-4 118791_1113
PAGE 75
Seat Service Parts, Standard INDEX NO. PART NO. QTY.
PAGE 76
Seat, Removable Back 1 3 2 6 1 4 7 8 2 5 12 9 11 10 11 7-6 118791_1113
PAGE 77
Seat, Removable Back INDEX NO. PART NO. QTY. DESCRIPTION 1 604874 1 SEAT, REMOVABLE BACK 2 551897 1 SEAT PAN (WITH DECAL) 3 604307 1 PUSH BUTTON MOUNT 4 086660 2 NT .375-16 NL G5 5 000331 1 WIRE TIE 6 768523 4 FW .343 X .687 X .051/.080H 7 079186 4 CS .312-18 X 1.25 HX G5 8 029629 3 CS .375-16 X .75 HX FLK 9 793851 3 COMPRESSION SPRING 1.25 X 4.00 X .188 10 016899 3 NT .375-16 HX FLK ZNYC 11 036244 2 CS .375-16 X 1.
PAGE 78
Seat Service Parts, Removable Back 1 2 3 4 INDEX NO. PART NO. QTY.
