Installation Guide

2 Wire Grids 15" wide (38cm) 1 Wire Grid 13" wide (33cm) 2 Support Bar Assemblies
4 Washers 9/64" (3 mm)
4 Carriage Bolts 9/64" x 1"
(3.0mm x 25mm)
4 Carriage Bolts ¼" x 2"
(6mm x 51mm)
Parts Included
4 Hex Nuts 9/64" (3 mm)
ASSEMBLY INSTRUCTIONS
45" x 45" Ceiling Storage Unit
Item # 00540
MISSING A PART? There is no need to return this item to the store. Instead, call us Toll Free 1-800-253-1561
Pencil
3/16"
Drill Bit
(4.8mm)
Power
Drill
Ladder or
Step Stool
Tape Measure
Eye Protection
7/16" &
1/2" Wrench
(11 mm & 13 mm)
Stud/Joist
Finder
(optional)
7/16" & 1/2"
Socket Wrench
or Nut Driver
Tools Required:
OR
Level
Joists
24" to 36"
apart
D
D
A
A
A
B
B C
F
E
E
G
G
H
H
I
J
K
HyLoft Sticker
2 Plastic Tie Straps
4 Hex Nuts Serrated ¼" (6mm)
4 Lag Screws 5/16" x 2 ½"
(8mm x 64mm)
1-800-253-1561
www.hyloft.com
