IRIS075 Day/Night Fixed Camera USER GUIDE & INSTALLATION MANUAL IRIS INNOVATIONS LIMITED Units 8 & 9 Swanwick Business Centre, Bridge Road, Swanwick, Hampshire SO31 7GB. UK IRIS INNOVATIONS USA CORPORATION 1535 SE 17TH Street, Suite 115, FT. Lauderdale, FL33316 USA www.boat-cameras.
Warnings & Regulatory Information Do not use harsh chemicals or cleaning solvents to clean the device. Do not attempt to dismantle the device. Unauthorized modifications or attachments could damage the device and may violate regulations governing radio devices. Any modification to the products cable tail may invalidate the product warranty. Please contact Iris Innovations before attempting any modification to the cable. Avoid dropping, knocking or excessively shaking the device.
Introduction The IRIS075 is a general purpose, fixed day / night camera with integrated infra red illumination designed into a streamlined low-profile waterproof housing. It’s unique and stylish housing, coupled with a high resolution day / night camera module that switches automatically from colour to monochrome at night or in low light conditions make it a perfect choice as a docking or backup camera, engine room camera, forward facing or walkway camera.
Installation To install the IRIS106 you will need the following tools: • Drill Bit for Pilot Holes (2mm) • 3mm Hex Key (Supplied) • Drilling Template (Supplied) • Hand tools for connecting cables (unless pre-made cables are being used), including wire cutters, wire stripper, and cross headed screw driver. • Appropriate tool for terminating BNC connector (unless pre-made cables are being used), such as knife to remove coax cable outer sheath and dielectric, BNC Crimp Tool, Cable Insulation Stripper.
fixtures in it's intended position (such as doors or walkways for example). If possible, power the item up and offer the camera up in the vicinity of the desired installation position to double check suitability. Cabling: The camera has a 45cm cable tail which has a 2.5mm DC Barrel Jack (female) to connect power and a 75Ω BNC (female) connector for the video signal, therefore it will be almost inevitable that the power, data and video cables will need to be extended.
Cabling (continued...) The following cable specifications apply: Video: 75Ω Coaxial Cable such as RG59, URM70, RG174 Mini-Coax. Power: 2 core. Rated 12VDC - max Current 1A Individual cables can be run for each of the above, or 'Combination' (Combi) cables can be used. Iris Innovations supply pre-made cables to length. Please contact Iris for more details.
2. Use the 3mm Hex key supplied to remove the 3 fixings that fasten the shell into the base plate. The shell, eyeball and T plate should now be free of the base plate. 3. You will notice that the eyeball features a slight lip on one edge. This is the sun-visor and should always be on the top of the eyeball perpendicular to the ground. Adjust the eyeball so it is in the desired orientation within the shell and hold in place. 4.
Fitting the Camera: Step 1: After you have established the desired mounting position and are happy there are no obstacles behind the surface into which you are drilling, over the stick on drilling template into position, ensure you observe the desired camera orientation before you stick the template down.
Step 3: Offer the base fixing plate into position as shown above and screw into place using self tapping screws appropriate for your install. Step 4: Now connect the cameras power and video cables to your extension cables and screw the ‘shell’ of the camera (containing eyeball) onto the base fixing plate using the 3mm Hex bolts supplied.
To do this, whilst the camera is powered up, tightly cup your hands around, or cover around the IR sensor on the front of the camera, making sure no light can get onto the face of the sensor. After a few seconds the LED should operate and you should see a feint red glow around the IR illuminator. The image on your screen should have also switched from Colour to Monochrome.
Limited Warranty This Iris Innovations product is warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, Iris will, at its sole option, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts or labour, provided that the customer shall be responsible for any transportation cost.
Iris Innovations Limited Units 8 & 9 Swanwick Business Centre Bridge Road, Swanwick, Hampshire SO31 7GB United Kingdom Tel: +44(0)1489 570797 Iris Innovations USA Corporation 1535 SE 17th Street, Suite 115 Fort Lauderdale, Florida 33316 United States of America Tel: +1 (954) 903 3666 info@boat-cameras.com www.boat-cameras.
