OPERATING MANUAL AND SAFETY INSTRUCTION FCC ID:2AACZ-M360A01 IS360.
CONTENTS English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 This Operating Manual complies with these standards: IEC 60079, IEC 82079, ANSI Z535.6 Diese Bedienungsanleitung erfüllt die Anforderungen der folgenden Normen: IEC 60079, IEC 82079, ANSI Z535.6 Document No. 1057MM01REV00 Version: 2021-08-27 (c) 2021 i.safe MOBILE GmbH i.
ENGLISH EX MARKINGS ATEX: II 3G Ex ic IIC T4 Gc II 3D Ex ic IIIC T135°C Dc EU Type Examination Certificate: EPS 21 ATEX 1 126 X CE-designation: IECEx: Ex ic IIC T4 Gc Ex ic IIIC T135°C Dc IECEx Certificate: IECEx EPS 21.0043X Temperature range: -10°C … +60°C (EN/IEC 60079-0) -10°C … +50°C (EN/IEC 62368-1) Manufactured by: i.
READ AND UNDERSTAND THE INSTRUCTIONS PROTECT YOUR LIFE AND READ THE OPERATING MANUAL This Operating Manual is part of the device IS360.2 (model M360A01). This Operating Manual provides important information for safe use of the device. Before using the device, read this Operating Manual carefully and pay particular attention to the “Safety” section and the warnings highlighted with the warning symbol. Also read the Safety Instructions before using the device. You can find these at www.isafe-mobile.
WARRANTY You can find the warranty conditions at www.isafe-mobile.com/en/support/service. For any damage caused by computer viruses that you download while using the Internet functions responsibility is at your hand. There is no right of recourse against i.safe MOBILE GmbH. EU DECLARATION OF CONFORMITY You will find the EU declaration of conformity at the end of this Operating Manual or at www.isafe-mobile.com/en/support/downloads.
DEVICE OVERVIEW/FUNCTIONS 1 2 13 14 3 4 12 15 5 6 7 8 9 10 11 16 6
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 3.5 MM AUDIO JACK: Connect to the 3.5mm headphone or the 3.5mm wired hand microphone. FUNCTION KEY: Optional key used by different apps. L ED INDICARTOR: Indicates charging and notification. POWER KEY: A long press switches the device on/off. A short press to turn on/off the display. FUNCTION KEY: Optional key used by different apps. LOUDNESS CONTROL: Volume up/Volume down. C URRENT APPLICATION: Shows all open applications.
SAFETY Read the “Safety” section of this Operating Manual carefully before using the device. If you do not follow these instructions or do not understand them, this could lead to death, severe injuries and damage to the device. USER Only trained users who are qualified in the use of Ex devices in explosion hazardous areas and who have read and understood this Operating Manual may use this device.
NOTICE Incorrect use can damage the device. Only use accessories approved by i.safe MOBILE, as described in the section on “Connecting approved accessories”. Protect the device and the Adapter from strong electrical magnetic fields as for example those emitted by induction cookers or microwave ovens, for example. Do not touch the display with sharp objects. POSSIBLE USER ERRORS DANGER Improper use can result in death or severe injuries! Follow the instructions below: Do not modify the device structurally.
INSTALLING THE BATTERY DANGER Installing the wrong battery in the device, poses a risk of explosion, which could result in death or serious injuries! Only fit the battery supplied or an approved replacement battery in the device outside of explosion hazardous areas. The approved replacement battery can be found on the website www.isafe-mobile.com/en/products. Loosen the screws on the battery compartment using the Screwdriver provided. Remove the battery compartment cover.
INSERT/REMOVE SIM CARD/MICROSD CARD DANGER An incorrect procedure in explosion hazardous areas poses a risk of death or severe injuries! Only open the device outside of explosion hazardous areas to insert or remove the SIM card. NOTICE Proceeding incorrectly when inserting/removing the SIM card/ SD card can damage the device and the SIM card/SD card. Switch off the device before inserting or removing a SIM card/ SD card. Do not charge the device while inserting or removing a SIM card.
Your device package contains a power supply, various country-specific power adapters and an Type C USB Cable. Connect the power adapter suitable for your country to the power supply. Connect the Type C USB Cable to the power supply. Connect the Type C USB Cable to the USB interface of the device. SWITCHING ON/OFF Press and hold the on/off key for about 3 seconds. Enter the device or SIM PIN when the input dialog for the device or SIM PIN appears after switching on.
CHANGING THE BATTERY WARNING If you replace the battery with the wrong battery in the device, there is a risk of explosion, which could result in death or serious injuries! Only replace the battery with an approved replacement battery outside of explosion hazardous areas. An approved replacement battery can be found on the website www.isafe-mobile.com/en/products. Loosen the screws on the battery compartment using the Screwdriver provided. Remove the battery compartment cover.
POSSIBLE DEVICE PROBLEMS You can find information on possible device problems and how to rectify them at www.isafe-mobile.com/en/support/service under the menu item “FAQ”. If you have any further questions, please contact the i.safe MOBILE repair service at www.isafe-mobile.com/en/support/service. MAINTENANCE/REPAIR The device itself has no serviceable parts.
Always dispose electronic products, batteries and packaging material at the appropriate collection points. This way, you prevent uncontrolled waste disposal and promote the recycling of material resources. You can obtain further information from regional waste disposal companies, state authorities or the i.safe MOBILE service centre responsible for your country or region at www.isafe-mobile.com/en/support/service. TRADEMARKS i.safe MOBILE and the i.safe MOBILE logo are registered trademarks of the i.
MAXIMUM OUTPUT POWER Frequency bands Maximum output power GSM 850 32.00 dBm GSM 900 32,72 dBm GSM 1800 28,28 dBm GSM 1900 29,66 dBm W1 21,32 dBm W2 21,43 dBm W4 21,86 dBm W5 22,38 dBm W8 22,52 dBm LTE band 1 21,51 dBm LTE band 2 21,95 dBm LTE band 3 22,48 dBm LTE band 4 22,48 dBm LTE band 5 22,69 dBm LTE band 7 21,38 dBm LTE band 8 22,69 dBm LTE band 20 22,88 dBm LTE band 28 23,21 dBm LTE band 38 22,91 dBm LTE band 40 22,92 dBm 22.95 fcc LTE band 41 22,82 dBm 22.
Restrictions in the 5 GHz band: According to Article 10 (10) of Directive 2014/53/EU, the packaging shows that this radio equipment will be subject to some restrictions when placed on the market in Belgium (BE),Bulgaria (BG), the Czech Republic (CZ),Denmark (DK), Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain(ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV), Lithuania(LT), Luxembourg (LU), Hungary (HU), Malta (MT), Netherlands (NL), Austria(AT), Poland (PL), Portugal (PT),
EU DECLARATION OF CONFORMITY EU – Declaration of Conformity EU – Konformitätserklärung according to directive 2014/34/EU, 2014/53/EU, 2012/19/EU, 2011/65/EU (2015/863/EU) nach Richtlinie 2014/34/EU, 2014/53/EU, 2012/19/EU, 2011/65/EU (2015/863/EU) The company i.safe MOBILE GmbH declares under its sole responsibility that the product to which this declaration relates is in accordance with the provisions of the following data, directives and standards: Die Firma i.
EU DECLARATION OF CONFORMITY Conformity statement 2014/53/EU; 2012/19/EU issued by Konformitätsaussage 2014/53/EU; 2012/19/EU ausgestellt durch Applied harmonized standards Angewandte harmonisierte Standards Notified Body: PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg Germany identification number / Kenn-Nummer: 0700 ETSI EN 301 489-1 V2.2.3; Draft ETSI EN 301 489-3 V2.1.2 ETSI EN 301 489-17 V3.2.4; Draft ETSI EN 301 489-19 V2.2.0; Draft ETSI EN 301 489-52 V1.1.2; ETSI EN 301 511 V12.5.
IC Statement for i.safe MOBILE IS360.X (Model M360A01) This device complies with Industry Canada licence-exempt RSS standard(s) Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
WWW.ISAFE-MOBILE.
