101
DeviceNet Gateway
8. Network System Building Procedure
8.1 Procedure
The procedure to start up a DeviceNet network using the gateway unit is shown below.
(1) Installation
Install the DeviceNet gateway unit, axis controller and other necessary units in the
control panel.
↓
(2) Wiring
Wire the gateway unit’s 24-V power supply and field network, and also wire for SIO
communication, etc.
(Refer to 4.)
↓
(3) Set the address of each axis controller (Refer to 4.3.2 and 8.2.)
Set the SIO baud rate of the axis controller (Refer to 8.2.)
↓
(4) Set the baud rate, node address and mode setting switch of the gateway unit. (Refer to
2.3 and 8.3.)
↓
(5) Set the node address and baud rate on the DeviceNet master side and assign the
master PLC address (Refer to 8.4.)
↓
(6) Create a controller position table
↓
(7) Create a PLC ladder sequence
