DeviceNet Gateway
4. Wiring
4.1 Overall Configuration
Shown below is an example of the DeviceNet system configuration using the Gateway Unit.
SIO communication network
Terminal resistor
4-way junction
Host system (PLC master)
Gateway
Unit
Teaching pendant
24-V
power
supply
Communication
power supply
T-junction
DeviceNet
Slave devices
Terminal
block
