33
DeviceNet Gateway
[2] Example of cutting off motor drive power
Teaching
pendant
Gateway Unit
EMG
pushbutton
TP connector
EMG
pushbutton
EMG
reset
switch
Gatewa
y
power suppl
y
Port
switch
SIO
communication
SIO connector
PCON, ACON controller
24-VDC input
power supply
(2 A max. per unit)
Powe
r
-supply
terminal block
Connection
detection
signal (H)
SIO
connector
connection
detection
circuit
EMG signal
detection (H)
Motor drive
power
Control
power
Time
cons-
tant
Drive stop
signal (L)
Motor
drive
circuit
Powe
r
-supply terminal block (unit 2)
Powe
r
-supply terminal block (unit 3)
