available.)
X'B0A0'--X'B0FF', X'B1A0'--X'C8FF' (Positions X'B100'--X'B19F' are not
available.)
X'CAA0'--X'CAFF', X'CBA0'--X'FDFF' (Positions X'CB00'--X'CB9F' are not
available.)
Simplified
Chinese GB2312-80 (Font selection X'1B', X'53', X'33')
X'A1A0'--X'A1FF', X'A2A0'--X'A9FF' (Positions X'A200'--X'A29F' are not
available.)
X'B0A0'--X'B0FF', X'B1A0'--X'F7FF' (Positions X'B100'--X'B19F' are not
available.)
Traditional
Chinese Big-5 (Font selection X'1B', X'53', X'34')
X'A140'--X'A1FF', X'A2A0'--X'C6FF' (Positions X'A200'--X'A23F' are not
available.)
X'C940'--X'C9FF', X'CA40'--X'F9FF' (Positions X'CA00'--X'CA3F' are not
available.)
Graphic display mode
1B 5C 3F 4C 47 Px 3B Py 3B Ph 3B Pw 3B Pd
Purpose:
This command specifies the graphic display mode. The control bytes
embedded in the command sequence (represented by Px, Py, Ph, and Pw
in the command format), change the graphic display characteristics. Pd
represents the data byte.
Px (display
position)
0 ∼ 159 (X'30' ∼ X'31', X'35', X'39')
Py (display
position)
0 ∼ 39 (X'30' ∼ X'33', X'39')
Ph (height) 1 ∼ 40 (X'31' ∼ X'34', X'30')
Pw (width) 1 ∼ 160 (X'31' ∼ X'31', X'36', X'30')
Pd The display data.
Double-size letter in horizontal
1B 23 Ps
Purpose:
This command sets a character with double-size letter in horizontal. It is
available for all full-size letter, all half-size letter, and ANK font.
Ps 5 = Normal-size letter
6 = Double-size letter in horizontal
Horizontal scroll on all lines
The format of the Horizontal Scroll Select command is as follows:
1B 5C 3F 4C 4D 53
Purpose:
This command sets horizontal scroll mode.
Input/output device commands
