Chapter 1. Introducing the IBM xSeries 445 server Your IBM®ERserver™xSeries® 445 server is a 4-U-high1 rack model server for high-volume network transaction processing. This high-performance server is ideally suited for networking environments that require superior microprocessor performance, efficient memory management, flexibility, and reliable data storage. Performance, ease of use, reliability, and expansion capabilities were key considerations in the design of your server.
v Hardware Maintenance Manual and Troubleshooting Guide This document is in PDF on the IBM xSeries Documentation CD. It contains information to help you solve problems yourself, and it contains information for service technicians. Depending on your server model, additional documentation might be included on the IBM xSeries Documentation CD. Your server might have features that are not described in the documentation that you received with the server.
Features and specifications The following information is a summary of the features and specifications of your server. Microprocessor: v Supports the following microprocessors: – Up to 8 Intel® Xeon MP microprocessors (16 in a 16-way configuration) Power supply: Environment: v Air temperature: Two hot-swap power supplies (depending – Server on: 10° to 35°C (50.0° to on model): 95.0°F). Altitude: 0 to 914 m (2998.7 v 550 watts at 110 V ac or 1050 watts at ft). 220 V ac – Server on: 10° to 32° C (50.
What your server offers Your server uses the following features and technologies: v IBM Director IBM Director is a workgroup-hardware-management tool that you can use to centrally manage xSeries servers. For more information about IBM Director, see the IBM Director User’s Guide on the IBM Director CD. v IBM Enterprise X-Architecture technology IBM X-Architecture technology combines proven, innovative IBM designs to make your Intel-processor-based server powerful, scalable, and reliable.
v Large data-storage capacity and hot-swap capability Your server supports up to two 25.4-mm (1-inch) slim-high, 3.5-inch hot-swap hard disk drives in the hot-swap bays. With the hot-swap feature, you can add, remove, or replace hard disk drives without turning off the server. v Light path diagnostics feature The light path diagnostics feature provides LEDs to help you diagnose problems. For more information, see the section about the light path diagnostics feature in the Installation Guide.
Reliability, availability, and serviceability features Three important computer design features are reliability, availability, and serviceability (RAS). The RAS features help to ensure the integrity of the data that is stored in your server, the availability of the computer when you need it, and the ease with which you can diagnose and repair problems.
Active Memory Active Memory is an IBM feature that improves the reliability of memory through memory mirroring, memory scrubbing, and the Memory ProteXion feature. Memory scrubbing and Memory ProteXion Memory scrubbing tests the memory at regular intervals to detect and report potential memory errors before they can cause server outages. If a detected error is recoverable, the Memory ProteXion feature corrects the error and rewrites the data to another memory location on the same DIMM.
IBM Director With IBM Director, a network administrator can: v View the hardware configuration of remote systems, in detail v Monitor the usage and performance of critical components, such as microprocessors, disks, and memory v Centrally manage individual or large groups of IBM and non-IBM Intel-based servers, desktop computers, workstations, and mobile computers on a variety of platforms IBM Director provides a comprehensive entry-level workgroup hardware manager.
Server controls, LEDs, and power The following section identifies the controls and indicators on the front and rear of your server.
SCSI activity LED: This green LED is lit when there is activity on the SCSI bus. Locator LED: The locator LED is on the left front of the Light Path Diagnostic drawer. This blue LED identifies the primary and secondary servers. This LED blinks on the primary server and remains lit solid on the secondary server. DVD-ROM drive eject button: Press this button to release a DVD-ROM drive from the server. DVD eject button: Press this button to release a DVD from the DVD-ROM drive.
Rear view System power connector 1 System power connector 2 RXE Expansion Port B Mouse connector Keyboard connector Remote Supervisor Adapter II - EXA connectors and LEDs Gigabit Ethernet connector Upper Ethernet status LED SMP Expansion Port 1 SMP Expansion Port 2 SMP Expansion Port 3 SCSI connector RXE Management Port Lower Ethernet status LED Gigabit Ethernet connector Video connector USB 1 USB 2 (not supported) RXE Expansion Port (A) Figure 2.
Remote Supervisor Adapter II-EXA connectors and LEDs: This group of connectors and LEDs on the back of the server is used for system-management information and control. External power connector Heartbeat LED (amber) RSA II - EXA breakout port Power LED (green) Ethernet activity LED (green) Ethernet link LED (green) Video port 10/100 Ethernet port Figure 4. Remote Supervisor Adapter II-EXA connectors and LEDs v External power connector: You can connect an optional ac power adapter to this connector.
v External power connector: You can connect an optional ac power adapter to this connector. v Error LED: This amber LED is lit when a system-management error has occurred. v ASM interconnect port: Connect signal cables for managing expansion-module resources to this port. v Ethernet activity LED: This green LED is lit when there is activity on the Ethernet LAN. v Ethernet link LED: This green LED is lit when the Ethernet link is active. v 10/100 Ethernet port: Connect Ethernet signal cables to this port.
SMP Expansion port 1: Use this port to interconnect two SMP Expansion Modules together. Server power features When the server is connected to an ac power source but is not turned on, the operating system does not run, and all core logic except for the service processor is shut down; however, the server can respond to requests from the service processor, such as a remote request to turn on the server. The power-on LED flashes to indicate that the server is connected to ac power but it is not turned on.
Turning off the server When you turn off the server and leave it connected to ac power, the server can respond to requests from the service processor, such as a remote request to turn on the server. To remove all power from the server, you must disconnect it from the power source. Some operating systems require an orderly shutdown before you turn off the server. See your operating-system documentation for information about shutting down the operating system.
16 xSeries 445 Type 8870: User’s Guide
Chapter 2. Configuring the server The following configuration programs and capabilities come with your server: v Configuration/Setup Utility program The Configuration/Setup Utility program is part of the basic input/output system (BIOS) code in your server. Use it to configure management port assignments, change interrupt request (IRQ) settings, change the startup-device sequence, set the date and time, and set passwords.
v Preboot Execution Environment (PXE) boot agent utility program The PXE boot agent utility program is part of the BIOS code in your server. Use it to change network startup (boot) protocols and startup order and to select operating-system wake-up support. For information about using this utility program, see “Using the PXE boot agent utility program” on page 70. Using the Configuration/Setup Utility program The Configuration/Setup Utility program is part of the BIOS code.
v System Information Select this choice to view information about your server. When you make changes through other options in the Configuration/Setup Utility program, some of those changes are reflected in the system information; you cannot change settings directly in the system information. This choice is on the full Configuration/Setup Utility menu only.
– Administrator Password Attention: If you set an administrator password and then forget it, there is no way to change, override, or remove it. You must replace the system board. Select this choice to set or change an administrator password. An administrator password is intended to be used by a system administrator; it limits access to the full Configuration/Setup Utility menu.
– – – – The following information applies to memory mirroring: - The hot-add memory feature allows you to add DIMMs without turning off the server. This feature is supported only in servers using Windows Server 2003 Enterprise or Datacenter editions. - To use the hot-add memory feature, memory mirroring must be Disabled. - To use the hot-replace memory feature, memory mirroring must be Enabled.
– System Error Log Select this choice to view the System Error log, which contains all system error and warning messages that have been generated. Use the arrow keys to move between pages in the log. Select Clear error logs to clear the System Error log. v Save Settings Select this choice to save the changes you have made in the settings. v Restore Settings Select this choice to cancel the changes you have made in the settings and to restore the previous settings.
1. If you have not already done so, connect the RXE expansion and RXE management cables between the server and the remote expansion enclosure. See ″RXE Expansion and Management Port cabling″ in the Option Installation Guide on the IBM xSeries Documentation CD. 2. Start the Configuration/Setup Utility program. 3. From the main menu, select Advanced Setup. 4. Select Scalable Partition Settings. 5. Select Create Scalable Partition Settings. 6.
9. Save and Exit the Configuration/Setup Utility Program. Note: See the software documentation that comes with your operating system to install your operating system. Deleting a scalable partition Complete the following steps to delete the scalable partition: 1. Start the Configuration/Setup Utility on the primary server. 2. From the main menu, select Advanced Setup. 3. Select Scalable Partition Settings. 4. Select either Delete ALL Scalable Partition or Delete ONLY Local Scalable Partition.
Passwords From the System Security choice, you can set, change, and delete a power-on password and an administrator password. The System Security choice is on the full Configuration/Setup menu only. Note: In a 16-way configuration, security settings are defined through the primary server. If you bypass the 16-way configuration during start up or start the servers in a stand alone configuration, you must define the security setting on each individual server.
While the server is turned off, move the switch to the position opposite its current position. You can then start the Configuration/Setup Utility program and reset the power-on password. You do not need to return the switch to the previous position. The power-on password override switch does not affect the administrator password. Administrator password If an administrator password is set, you must type the administrator password for access to the full Configuration/Setup Utility menu.
Using the ServerGuide Setup and Installation CD The ServerGuide Setup and Installation CD includes an easy-to-use setup and installation program that is designed for your IBM server. The ServerGuide program detects the server model and hardware options that are installed and uses that information during setup to configure the hardware. The ServerGuide program simplifies operating-system installations by providing updated device drivers and, in some cases, installing them automatically.
Setup and configuration overview When you use the ServerGuide Setup and Installation CD, you do not need setup diskettes. You can use the CD to configure any supported IBM server model. The setup program provides a list of tasks that are required to set up your server model. On a server with a ServeRAID adapter or integrated SCSI controller with RAID capabilities, you can run the SCSI RAID configuration program to create logical drives.
The following table contains information about the supported operating systems. Note: All listed operating systems are supported by the Remote Supervisor Adapter. Table 1.
Configuring the Gigabit Ethernet controller The Ethernet controller is integrated on the system board. It provides an interface for connecting to a 10-Mbps, 100-Mbps, or 1-Gbps network and provides full-duplex (FDX) capability, which enables simultaneous transmission and reception of data on the network.
Complete the following steps to start the LSI Logic Configuration Utility program: 1. Turn on the server. 2. When the prompt <<< Press to start LSI Logic Configuration Utility >>> appears, press Ctrl+C. If you have set an administrator password, you are prompted to type the password. 3. Use the arrow keys to select a controller (channel) from the list of adapters; then, press Enter. 4. Follow the instructions on the screen to change the settings of the selected items; then, press Enter.
Configuring the controller By running ServeRAID Manager in Startable CD mode, you can configure the controller before you install your operating system. The information in this section assumes that you are running ServeRAID Manager in Startable CD mode. To run ServeRAID Manager in Startable CD mode, turn on the server; then, insert the CD into the DVD-ROM drive.
Using express configuration Complete the following steps to use express configuration: 1. In the ServeRAID Manager tree, click the controller. 2. Click Express configuration. 3. Click Next. The “Configuration summary” window opens. 4. Review the information in the “Configuration summary” window. To change the configuration, click Modify arrays. Figure 7. “Configuration summary” window 5. Click Apply; then, click Yes when asked if you want to apply the new configuration.
Using custom configuration Complete the following steps to use custom configuration: 1. In the ServeRAID Manager tree, click the controller. 2. Click Custom configuration. 3. Click Next. The “Create arrays” window opens. Figure 8. “Create arrays” window 4. From the list of ready drives, select the two drives that you want to group into the array. 5. Click (Add selected drives) to add the drives to the array. 6. If you want to configure a hot-spare drive, complete the following steps: a.
Figure 9. “Configuration summary” window 8. Review the information in the “Configuration summary” window. To change the configuration, click Back. 9. Click Apply; then, click Yes when asked if you want to apply the new configuration. The configuration is saved in the controller and in the physical drives. 10. Exit from ServeRAID Manager and remove the CD from the DVD-ROM drive. 11. Restart the server. Chapter 2.
Viewing the configuration You can use ServeRAID Manager to view information about RAID controllers and the RAID subsystem (such as arrays, logical drives, hot-spare drives, and physical drives). When you click an object in the ServeRAID Manager tree, information about that object appears in the right pane. To display a list of available actions for an object, click the object and click Actions. Figure 10.
Getting assistance For more information about ServeRAID Manager, see the online help system. To start the help system, click Help on the toolbar or select an item from the Help menu. Figure 11. ServeRAID Manager help menu Chapter 2.
The help system (ServeRAID Assist) will open within the ServeRAID Manager interface. Figure 12. Hints and tips feature To learn more about the ServeRAID Manager tree objects and the actions that apply to them, select a tree object and click Actions ⇒ Hints and tips. ServeRAID Assist will start, and information about the tree object will appear in the right pane of ServeRAID Manager.
Remote Supervisor Adapters This section describes how to identify the Remote Supervisor Adapter by its features and prerequisites for setup. It also explains how to cable and configure a Remote Supervisor Adapter or Remote Supervisor Adapter II-EXA for use on an Advanced System Management (ASM) network so that you can manage the server from a remote location. For more detailed information, see the appropriate Remote Supervisor Adapter User’s Guide on the IBM xSeries Documentation CD.
Setting up the Remote Supervisor Adapter II-EXA This section describes features, setup requirements, and how to cable and configure the Remote Supervisor Adapter II-EXA for use on an Advanced System Management (ASM) network so that you can manage the server from a remote location. For more detailed information, see the Remote Supervisor Adapter II User’s Guide on the IBM xSeries Documentation CD.
v The remote disk function requires the following software: – Server (for the server operating system to support the remote disk): Microsoft Windows 2000 with Service Pack 3 or above. – Client: Microsoft Windows 2000 or above and the Java™ 1.4 Plug-in or later. v To configure the remote alert recipients for Director over LAN or Director over modem, the remote alert recipient must be an IBM Director-enabled server with UM Server Extensions.
The RSA II-EXA breakout cable: The ASM breakout cable connects the Remote Supervisor Adapter II-EXA to the ASM interconnect network, the server USB port, and an external modem. ASM RS-485 connector USB connector Management connectors Figure 15.
Cable the Remote Supervisor Adapter II-EXA: This section provides the information needed to cable the Remote Supervisor Adapter II. 1. Connect the RSA II-EXA breakout cable to the RSA II-EXA breakout port on the server. Figure 16. Connect the RSA II-EXA breakout cable to the server 2. Connect the video cable from your video device to the video port on the Remote Supervisor Adapter II-EXA. 3. Plug the USB connector on the RSA II-EXA breakout cable into one of the USB ports on the rear of the server.
b. Check the Remote Supervisor Adapter II-EXA Ethernet link and activity LEDs. The location of the LEDs are shown in the following illustration. External power connector Heartbeat LED (amber) RSA II - EXA breakout port Power LED (green) Video port Ethernet activity LED (green) Ethernet link LED (green) 10/100 Ethernet port Figure 18. Remote Supervisor Adapter II-EXA connectors v External power connector: You can connect an optional ac power adapter to this connector.
For Microsoft Windows 2000 or Windows Server 2003: If the server in which the Remote Supervisor Adapter II-EXA is installed is running the Microsoft Windows 2000 or Windows Server 2003 operating system, you will need to download one file, which contains the following software and firmware: v Software and firmware installation instructions v Video adapter basic input/output system (BIOS) update v IBM Eserver xSeries BIOS update with support for the Remote Supervisor Adapter II-EXA v Diagnostics code update v
v IBM Eserver xSeries BIOS update with support for the Remote Supervisor Adapter II-EXA v Diagnostics code update v Remote Supervisor Adapter II-EXA device drivers v Remote Supervisor Adapter II-EXA firmware code update v Advanced Settings Utility program The software and firmware files that you need are contained in one system service package for Linux installation kit. Complete the following steps to locate and download the package file: 1. Go to http://www.ibm.com/pc/support/. 2.
v Controlling the server remotely v Virtually attaching a remote diskette drive, CD-ROM drive, or disk image to the server If you want to set up an ASM interconnect network and have not already done so, continue with “Configuring and connecting to the ASM interconnect network.” If you do not want to set up an ASM interconnect network, your configuration is now complete.
An ASM interconnect network can have up to 24 RS-485 connections, depending on the configuration. The connections can include Remote Supervisor Adapter II-EXAs, Remote Supervisor Adapter IIs, Remote Supervisor Adapters, ASM processors, ASM PCI adapters, and ISMPs.
resources, enabling Remote Supervisor Adapters, ASM processors, ASM PCI adapters, and ISMPs on the ASM interconnect network to send alerts using a modem or the network, even if they do not have a modem or network connection physically attached. Note: ISMPs can use the communications resources of a Remote Supervisor Adapter, Remote Supervisor Adapter II-EXA, or Remote Supervisor Adapter II only.
ASM interconnect network configuration examples: The illustrations in this section show sample ASM interconnect network configurations. In the following example, an Ethernet cable connects the remote system management administrator’s system to the Remote Supervisor Adapter II-EXA that is installed in an xSeries 445.
In the following example, a Remote Supervisor Adapter II-EXA is installed in an xSeries 44, and creates an interconnect network with the other xSeries 445 servers that have a Remote Supervisor Adapter installed.
Setting up the Remote Supervisor Adapter This section describes features, setup requirements, and how to cable and configure the Remote Supervisor Adapter for use on an Advanced System Management (ASM) network so that you can manage the server from a remote location. Note: The information in this section is intended for use with the Remote Supervisor Adapter, not the Remote Supervisor Adapter II-EXA.
v To configure the remote alert recipients for Director over LAN or Director over modem, the remote alert recipient must be an IBM Director-enabled server with UM Server Extensions. v If you want to use a Web browser to access the Remote Supervisor Adapter remotely, the following software is required: – Microsoft Internet Explorer 4.0 (with Service Pack 1), or later – Netscape Navigator 4.72, or later (version 6.
Cabling the Ethernet LAN port and management port: This section describes how to cable the Remote Supervisor Adapter. You can manage the server remotely through the Remote Supervisor Adapter using one of the user interfaces and one of the connection methods that are described in Table 2. Select the interface method you want to use to perform remote management; then, perform the indicated cabling procedure.
2. Check the Ethernet LEDs to ensure that the network connection is working. The following illustration shows the location of the LEDs. External power connector Error LED (amber) Power LED (green) ASM interconnect port Ethernet activity LED (green) Ethernet link LED (green) Management port 10/100 Ethernet port Figure 21. Remote Supervisor Adapter connectors v External power connector: You can connect an optional ac power adapter to this connector.
Note: For detailed information about using the ASM Web interface and the text-based user interface, see the Remote Supervisor Adapter User’s Guide on the IBM xSeries Documentation CD. Table 3.
3. Use the arrow keys to select Ethernet Settings; then, press Enter. The Ethernet Settings window opens, as shown in the following illustration. Note: The values in the window are only examples; your settings might be different. Figure 22. Ethernet Settings window with Web-based remote values 4. Use the arrow keys to navigate to each field.
10. Use the arrow keys to select Exit Utility from the menu or press Esc to close the Utility program. 11. Remove the diskette from the server. The server restarts automatically. 12. If you also want to configure the management port, continue with “Configuring the management port for text-based remote access.” Otherwise, go to “Installing Advanced System Management device drivers” on page 61.
You can dedicate the integrated management port on the Remote Supervisor Adapter to system management or share it with the operating system. If the management port is dedicated to system management, it serves only the Remote Supervisor Adapter and is always available for dial-in or dial-out alerting purposes. You cannot view the port using the operating system or any application.
The PPP Settings window opens, as shown in the following illustration. Note: The values in the window are only examples; your settings might be different. Figure 24. Ethernet Settings window setting up point-to-point protocol 4. Use the arrow keys to navigate to each field. Verify the values in the following fields: Network Interface The default is Disabled. Change this field to Enabled. IP Address The default value is 192.96.1.1.
7. Press Esc to return to the Configuration Settings window. If you need to configure the management port, go to “Configuring the management port for text-based remote access” on page 58. 8. Press Esc to return to the Utility program main window. 9. Use the arrow keys to select Exit Utility from the menu or press Esc to close the Utility program. 10. Remove the diskette from the diskette drive. The server restarts automatically. 11. Continue with “Installing Advanced System Management device drivers.
3. If you are installing from a CD, type: d:\DD\WIN2000\SETUP, where d is the drive letter of the DVD-ROM drive. 4. Follow the directions that display on the screen. 5. Go to “Configuring the remote control password” on page 63. Installing Windows NT ASM device drivers: Select one of the following methods to install the ASM device drivers for Windows NT: v Non-interactive The non-interactive method for installing the ASM device drivers accepts the default values for any window prompts that appear.
Configuring the remote control password: If you want to use the remote control features of the Remote Supervisor Adapter ASM Web interface, you must configure the remote control password using the Configuration/Setup Utility program that comes with the server. This program is part of the basic input/output system (BIOS) code. To set up a remote control password, complete the following steps: 1. Start the server, and watch the monitor screen. 2.
where other Remote Supervisor Adapters, ASM processors, and ASM PCI Adapters on the network reside. Second, the ASM interconnect network enables other interconnect network devices to use the resources (Ethernet or modem) of other Remote Supervisor Adapters, ASM processors, and ASM PCI Adapters in the ASM interconnect network for sending alerts.
communications resources are available for use by other servers on the ASM interconnect network. These resources are then used as ASM interconnect network resources, enabling Remote Supervisor Adapters, ASM processors, or ASM PCI adapters on the ASM interconnect network to send alerts using a modem or the network, even if they do not have a modem or network connection physically attached.
Server name ASM Interconnect module needed xSeries 220 yes xSeries 232 yes xSeries 240 yes xSeries 330 The ASM interconnect module is required to link the Remote Supervisor Adapter to the microprocessor in the server. Use the RS-485 ports to create the ASM interconnect network.
Figure 25. Connecting an ASM Interconnect module to an xSeries 445 server 2. Connect one or two Category 3 or Category 5 Ethernet cables to the other end of the ASM Interconnect module. 3. Continue with “ASM interconnect network configuration examples” on page 68. Chapter 2.
ASM interconnect network configuration examples: The illustrations in this section show sample ASM interconnect network configurations. The following illustration shows an Ethernet cable connecting the remote administrator system to the Remote Supervisor Adapter that is installed in an xSeries 445. Server 1 uses the LAN connection to forward system-management data generated by the other xSeries 445 server in the ASM interconnect network bus to the remote system-management administrator.
The following illustration shows a modem connected to the management port of the Remote Supervisor Adapter in the xSeries 445 server on the left, a modem connected to the management port of the Remote Supervisor Adapter in the xSeries 445 server on the right, and a modem connected to the remote administrator system.
Using the PXE boot agent utility program Use the Preboot Execution Environment (PXE) boot agent utility program to enable or disable operating-system wake-up support. Note: Your server does not support changing the network boot protocol or specifying the startup order of devices through the PXE boot agent utility program. Starting the PXE boot agent utility program Complete the following steps to start the PXE boot agent utility program: 1. Turn on the server. 2.
