4.LocatetheiButtonsocketonthesystemboard.Opentheretainingclip1ontheiButtonsocketto
releasethesystemboardRAID5keyandthencompletelyremovethekeyfromtheiButtonsocket.
Note:Ifnecessary,removeanypartsordisconnectanycablesthatmightimpedeyouroperation.
Figure46.RemovingthesystemboardRAID5key
5.IfyouareinstructedtoreturntheoldsystemboardRAID5key,followallpackaginginstructionsand
useanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage162.Asthe
onboardSATAsoftwareRAID5isnotavailablewithoutthesystemboardRAID5key,youmightneedto
recongureRAIDforyourserver.See“ConguringRAID”onpage71
.
InstallingorremovingtheThinkServeriKVMRemoteManagement
Module
ThistopicprovidesinstructionsonhowtoinstallorremovetheThinkServeriKVMRemoteManagement
Module(hereinafterreferredtoastheiKVMkey).
TheiKVMkeyoffersconvenient,remoteKVMaccessandcontrolthroughtheLANorInternet.Youcanuse
theiKVMkeytogainlocation-independentremoteaccesstorespondtocriticalincidentsandtoundertake
necessarymaintenance.Therefore,workingasanintegratedsolutioninyourserver,theiKVMkeyprovides
Chapter6.Installing,removing,orreplacinghardware105
