Thefollowingillustrationshowsthecomponentsoftheserverwithuptoeight2.5-inchhot-swapSAS
harddiskdrives.
Figure12.Componentsoftheserverwithuptoeight2.5-inchhot-swapSASharddiskdrives
1DITmodule(availableinsomemodels)
11Harddiskdrivebay1
2Frontpanel12Harddiskdrivebay0
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
13Frontsystemfan1
4Opticaldrivebay1(withanopticaldriveinstalled)14Systemboardbattery
5Harddiskdrivebay715Expansioncard
6Harddiskdrivebay6
16Heatsinkandfanassembly
7Harddiskdrivebay5
17Systemboard
8Harddiskdrivebay4
18Rearsystemfan
9Harddiskdrivebay319Powersupply
10Harddiskdrivebay2
20Fourmemoryslots(installedmemorymodulesvaryby
model)
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
Note:TheDITmodule1isonlyavailableinsomemodelsandtheDITpanelalsovariesbymodel.
See“DITmodule”onpage18.
•Thereisa2.5-inchhot-swapSASharddiskdriveoradummyharddiskdrivetrayinstalledineach
harddiskdrivebay(5to12).
