Index Description FRU
Number
3 KEYBOARD ASM 02K5916
KEYBOARD ASM (i-Series) 02K5923
KEYBOARD ASM US for s31 02K5917
KEYBOARD ASM Traditional Chinese
for s31
02K6170
KEYBOARD ASM Korean for s31 02K6172
4 HARD DISK DRIVE ASM 20 GB for
s30 (includes HDD bracket, see MISC
PARTS-b)
08K9612
HARD DISK DRIVE ASM 15 GB for
s31 (includes HDD bracket, see MISC
PARTS-b)
08K9691
HARD DISK DRIVE ASM 30 GB for
s31 (includes HDD bracket, see MISC
PARTS-b)
08K9689
5 MODEM CARD ASM for s30 08K3137
MODEM CARD ASM for s31 26P8219
6 IEEE 1394/LAN CARD 26P8100
WIRELESS CARD (s30 only) 08K3309
7 SYSTEM BOARD ASM PIII600/300,
128 MB
12P3639
8 PCMCIA SLOT 26P9297
9 BASE COVER ASM (WW) w/ RJ-45 26P9302
BASE COVER ASM (WW) w/o RJ-45 26P9339
10 TRACKPOINT CAP 84G6536
11 FAN ASM 26P9300
12 HARD DISK DRIVE FPC ASM 27L0647
13 POWER BOARD ASM 26P8048
14 SUSPEND BOARD 26P8049
Description FRU Number
AC Adapter 56W (2 PIN) Delta for s30 02K6548
AC Adapter 56W (2 PIN) Sanken for s30 02K6554
AC Adapter 56W (3 PIN) Delta for s31 02K6550
AC Adapter 56W (3 PIN) Sanken for s31 02K6555
SCREW KIT 26P9301
TELEPHONE CABLE US 27L0478
32 MB DIMM 20L0263
64 MB DIMM 20L0264
128 MB DIMM 20L0265
6-CELL BATTERY for s30 02K6786
6-CELL BATTERY for s31 02K6895
ThinkPad s30, s31 65
