OPERATION
■ Receiving and transmitting
RECEIVING:
➀ Push [ ] to turn power ON.
➁ Push [CH UP]/[CH DN] to select a channel.
➂ When receiving a call, adjust the volume to comfortable lis-
tening level.
TRANSMITTING:
➃ Lift the microphone off the microphone hanger.
• 5-tone mute may be released (the ‘audible’ condition is selected
and “[]” appears.
• A priority channel may be selected automatically.
➄ Wait for the channel to become clear.
• The channel is busy when “[]” appears.
➅ Push the [CALL] key when initiating a call from your side.
• Coded audio may be heard from the transceiver, then “[]” ap-
pears.
• This step may not be necessary depending on your signalling
system. Ask your system operator or dealer.
➆ While pushing and holding [PTT], speak into the micro-
phone at your normal voice level.
➇ Release [PTT] to receive.
IMPORTANT: To maximize the readability of your signal:
• Pause briefly after pushing [PTT].
• Hold the microphone 15 to 20 cm from your mouth, then
speak into the microphone at a normal voice level.
D Transmitting notes
• Transmit inhibit function
The transceiver has several lockout/inhibit functions which re-
stricts the transmission under the following conditions:
➥ The channel is in mute condition (‘inaudbile’ condition;
“
[]
” does not appear).
➥ Channel is busy.
➥ Not matched (or matched) CTCSS is being received.
➥ The selected channel is a ‘receive only’ channel.
• Time-out timer
After continuous transmission for a pre-programmed period,
the time-out timer is activated causing the transceiver to stop
transmitting and automatically select receive.
• Penalty timer
Once the time-out timer is activated, transmission is further
inhibited for a period determined by the penalty timer.
