Operation Manual

OPERATION

D Tx code channel selection

If the transceiver has the [TX CH] key, display can be toggled

with the operating channel number (or name) and Tx code

channel number (or name). When the Tx code channel num-

ber (or name) is displayed, the [ ]/[ ] key selects the Tx

code channel.

TO SELECT A TX CHANNEL:

➀ Push [TX CH]—a Tx code channel appears.

➁ Push [ ]/[ ] to select the desired Tx code channel.

➂ Push [CALL] to transmit the selected Tx code.

➃ Push [TX CH] again to return to the channel display.

FOR TX CODE CHANNEL TYPE:

When the [STN UP] and/or [STN DN] are available on the

transceiver, a TX code channel may appear constantly. In this

case, these keys select the TX code channel directly.

D Tx code number selection

If the transceiver has the [CODE] key, Tx code contents can

be changed within the allowable digits.

TO SELECT A TX CODE:

➀ Push [CODE]—a Tx code number appears and an allow-

able digit ﬂashes.

➁ Enter the desired number directly using the keypad.

• Repeat from step ➀ when you want to enter another Tx code.

➂ Push [CALL] to transmit the selected Tx code.

D DTMF transmission

If the transceiver has the [CODE] key, the automatic DTMF

transmission function is available. Up to 10 DTMF channels

may be available.

TO SELECT A TX CODE:

➀ Push [DTMF]—a DTMF channel appears.

➁ Push [ ]/[ ] to select the desired DTMF channel.

➂ Push and hold [DTMF] to transmit the DTMF code in the

selected DTMF channel.
