PANEL DESCRIPTION
EMERGENCY KEY
Push and hold the key to transmit an emergency
call.
• If you want to cancel the emergency call, push (or push and hold)
the key again before transmitting the call.
• The emergency call is transmitted one time only or repeatedly until
receiving a control code, depending on the pre-settting.
TX CODE KEY
Selects a transmit 5-tone code (station code) chan-
nel.
• Push and hold to change the contents of the station code using the
[CH UP]/[CH DN] keys.
• Push to select a TX 5-tone code channel using the [CH UP]/[CH
DN] keys after pushing this key.
ID MEMORY READ KEY
➥ Recalls detected ID codes.
• Push this key, then push [CH UP]/[CH DN] for selec-
tion.
• Up to 5 ID’s are remembered.
➥ Push and hold this key to erase all memorized ID’s.
OPTION KEY
TRUNKING GROUP KEY
Push to select a trunking group (when operating in
SmarTrunk II™ mode).
D Programmable functions without supplied
stickers
TX CODE CHANNEL UP/DOWN KEY
Push to select a TX code channel directly.
CHANNEL UP/DOWN FUNCTION
When a key is assigned this function, push it to increment or
decrement the operating channel.
CHANNEL SELECT FUNCTION
When a key is assigned this function, push it to increment or
decrement the operating channel.
BANK UP/DOWN FUNCTION
When a key is assigned this function, push it to increment or
decrement the selected channel bank.
PRIORITY CHANNEL A REWRITE FUNCTION
When a key is assigned this function:
➥ Push momentarily to select PRIO A channel.
➥ Push and hold to set the current channel to PRIO A.
DTMF RE-DIAL FUNCTION
When a key is assigned this function, push it to automatically
re-dial the most recent (manually transmitted) DTMF code.
EMER
CODE
ID MR
OPT
GRP
