Instruction Manual

OPTIONAL UNIT INSTALLATION
23
8
You can install two of the following optional units in the transceiver.
UT-105
SmarTrunk II
TM
Logic Board , UT-109/UT-110 VOICE SCRAMBLER
UNIT , UT-111 TRUNKING BOARD , UT-113 MAN DOWN UNIT .
‘‘
Installation
q Unscrew 1 nut a, and remove the knobs.
w Unscrew 1 screw b, 2 screws c then remove multi-connector
cover and rear panel.
e Unscrew 2 screws d, then remove multi-connector.
r Unscrew 2 screws e then take off the chassis from the front
panel in the direction of the arrow.
Be careful!: Flat cable is connected between the MAIN unit on the
chassis and front panel.
t Install the desired optional unit. Insert tightly to avoid bad contact.
y Program the necessary information with the cloning software be-
fore operation. Please ask your dealer or system operator for de-
tails.
