7 port USB 3.0 Hub
with 3 charge ports
Key features
• 7 port USB 3.0 Type-A hub
• 1x QC 3.0 charge port, 2x fast charge ports
• Flexible mounting options with the desktop or wall-mount bracket
• Incl. 12 V / 5 A power adapter and USB 3.0 cable to hostcomputer
• Transfer rate up to 5 Gbit/s
• Aluminium case
• Plug & Play
Attached to help
The IB-HUB1703-U3 is specially adapted to compete in industrial environments. The high-quality aluminium housing can withstand a lot and ensures effective heat dis-
sipation. Thanks to the mounting brackets, it can be mounted and used almost anywhere. In addition to the two highly efficient QC 3.0 charging ports, one fast charge
port (BC 1.2) and four USB 3.0 ports are integrated.
Packing content
1x IB-HUB1703-QC3, 1x USB 3.0 Type-B to Type-A cable,
710 mm length, 1x Power adapter, 1x Quick installation guide
Model
Article no.
EAN code
Brand
Colour
Material
Interface to hostcomputer
Interface to devices
IB-HUB1703-QC3
60362
4250078166849
ICY BOX
Black
Aluminium
1x USB 3.0 Type-A
7x USB 3.0 Type-A
1x QC 3.0 charge port: max. 18 W
2x fast charge ports: max. 12 W for each port,
comply with the battery charging specification
(BC 1.2)
Technical data
Chipset
Charging spezification
Plug & Play
Power switch
Transfer rate
LED
Power adapter
Operating system
VL817
USB 3.0: 5 V / 0,9 A, max. 4,5 W
QC 3.0: 3,6 - 12 V / 0 - 5 A, max. 18 W
USB-BC 1.2: 5 V / 2,4 A, max. 12 W
Total output: 12 V / 5 A, max. 60 W
Yes
Yes
Up to 5 Gbit/s
Power
Input: 100-240 V
Output: 12 V / 5 A
Windows
®
and macOS
®
ICY BOX
IB-HUB1703-QC3
