Datasheet

7
LD6A LED SignaLights
Assembled Products
Package Quantity: 1
Mounting Style Tiers
LED Color
Code
Steady Steady/Flashing/Alarm
Type No. Weight (approx.) Type No. Weight (approx.)
Frame Mount
1 R, Y, S, G, W
LD6A-1GQ*-
220g
LD6A-1GZQ*-
310g
2 RY, RG
LD6A-2GQ*-
260g
LD6A-2GZQ*-
350g
3 RYS, RYG
LD6A-3GQ*-
300g
LD6A-3GZQ*-
390g
4 RYSG
LD6A-4GQ*-
340g
LD6A-4GZQ*-
430g
5 RYSGW
LD6A-5GQ*-
380g
LD6A-5GZQ*-
470g
Wall Mount
1 R, Y, S, G, W
LD6A-1WQ*-
225g
LD6A-1WZQ*-
315g
2 RY, RG
LD6A-2WQ*-
265g
LD6A-2WZQ*-
355g
3 RYS, RYG
LD6A-3WQ*-
305g
LD6A-3WZQ*-
395g
4 RYSG
LD6A-4WQ*-
345g
LD6A-4WZQ*-
435g
5 RYSGW
LD6A-5WQ*-
385g
LD6A-5WZQ*-
475g
Direct Mount
1 R, Y, S, G, W
LD6A-1DQ*-
185g
LD6A-1DZQ*-
275g
2 RY, RG
LD6A-2DQ*-
225g
LD6A-2DZQ*-
315g
3 RYS, RYG
LD6A-3DQ*-
265g
LD6A-3DZQ*-
355g
4 RYSG
LD6A-4DQ*-
305g
LD6A-4DZQ*-
395g
5 RYSGW
LD6A-5DQ*-
345g
LD6A-5DZQ*-
435g
Pole Mount
(with base)
1 R, Y, S, G, W
LD6A-1PQ*-
645g
LD6A-1PZQ*-
735g
2 RY, RG
LD6A-2PQ*-
685g
LD6A-2PZQ*-
775g
3 RYS, RYG
LD6A-3PQ*-
725g
LD6A-3PZQ*-
815g
4 RYSG
LD6A-4PQ*-
765g
LD6A-4PZQ*-
855g
5 RYSGW
LD6A-5PQ*-
805g
LD6A-5PZQ*-
895g
Pole Mount
(with L-shaped
bracket)
1 R, Y, S, G, W
LD6A-1KQ*-
640g
LD6A-1KZQ*-
730g
2 RY, RG
LD6A-2KQ*-
680g
LD6A-2KZQ*-
770g
3 RYS, RYG
LD6A-3KQ*-
720g
LD6A-3KZQ*-
810g
4 RYSG
LD6A-4KQ*-
760g
LD6A-4KZQ*-
850g
5 RYSGW
LD6A-5KQ*-
800g
LD6A-5KZQ*-
890g
Specify a housing color code in place of • *: B (dark gray), W (light gray)
Select the illumination color from the top tier specifying the LED color code from the left. •
：
R (red), Y (yellow), S (blue), G (green), W (pure white)
Ordering Non-Standard Products
Order according to the table above. Specify the illumination color from the top tier. •
Example: When the LED color is RYGSW => LD6A-5GQW-RYGSW
Clear lens type also available. Specify “C” after the LED color code. •
Example: LD6A-5GQW-RYSGW => LD6A-5GQW-RYSGWC
Combination of LED Color and Lens Color •
LED Color Color Lens Type Clear Lens Type
R: Red Red lens Clear lens
Y: Yellow Yellow lens Clear lens
S: Blue Blue lens Clear lens
G: Green Green lens Clear lens
W: Pure white Clear lens
For pure white (W) LED, a clear lens is used in both color and clear lens congurations.
Supplied Parts •
Mounting Style Supplied Parts
Frame mount
M4 screw (4 pcs)*,
M4 spring washer (4 pcs)* , M4 plain washer (4 pcs)*, M5 screw (2 pcs),
M5 spring washer (2 pcs), M5 plain washer (2 pcs), bracket (1 pc)
Wall mount
M4 screw (20 mm) (4 pcs), M4 screw (8 mm) (4 pcs)*, M4 spring washer (8 pcs)*, M4 plain washer (8 pcs)*,
M4 nut (4 pcs), bracket (1 pc), gasket (1 pc)
Direct mount
M5 screw (4 pcs)*,
M5 spring washer (4 pcs)*, M5 plain washer (4 pcs)*, M5 nut (4 pcs)*, O-ring (4 pcs),
gasket (1 pc)
Pole mount
(with base)
M5 screw (4 pcs), M5 spring washer (4 pcs), M5 plain washer (4 pcs), M5 nut (4 pcs), O-ring (4 pcs),
gasket (1 pc)
Pole mount
(with L-shaped bracket)
M22 plain washer 2 (pcs), M22 nut (2 pcs), bracket (1 pc)
* For dark gray housing, black screws and washers are supplied. For light gray housing, silver screws and washers are supplied.
