User's Manual

Active UHF Beacon Tag
i-B2L P Marker Version — Preliminary
Beyond RFID.
IDENTEC SOLUTIONS' ILR i-B2L P tags are designed to be cost
effective, easy to implement and maintain offering maximum flexibility.
The beacon tags are continually send out their ID at pre-programmed
intervals. They do not need to be interrogated in order for them to
send their information—they do it automatically.
The Marker technology allows selective locating of a transponder for
example in adjacent car tracks. Here the inductive Marker field informs
the transponder about its current location. In a moment the
transponder sends its location information several times to a central
unit. For this data transmission it uses its long range RFID abilities.
Even after the transponder has left the Marker field it transmits this
data steadily at a configurable ping rate.
The i-B2L series offers an attractive price for continuous monitoring
and optimisation of logistics in the supply chain.
The main applications are:
 Access control
 Tracking of Vehicles and Containers
 Online inventory
 Localization of assets or personnel at specific areas
(i.e. gates, dock doors)
Using advanced UHF radio frequency technology, i-B2L tags send data at distances of up to 100 meters (300 feet) to either a mobile
(handheld) or fixed reader (interrogator).
Due to the ultra-low power consumption and configurable ping rate from 0.5 seconds up to 1 minute, the battery lifetime is very long.
The i-B2L tag from IDENTEC SOLUTIONS is the most economical choice for typical long range RFID applications and an ideal solutions for
tracking and tracing of mobile objects.
Features Benefits
 100 meter read range Allows the longest read-range for identification and tracking using beacon technology.
 Long battery lifetime Delivers long time maintenance-free operation, without battery replacement. The
battery lifetime depends mainly on the ping rate, which is configurable.
 Customizable ping rate To optimize battery consumption, dynamic appearance and RF band use.
 UHF operating frequencies Tags are available for both standard North American and European ISM band
frequencies.
 Non-line-of-sight data transmission Allows tags to be identified without the need of visual contact.
 Automatic transmission Tags do not have to be “woken”—they transmit automatically.
 Cost-effective Creates the economical conditions for the usage of active high performance RFID
technology to track and trace objects.
