User guide

AC-KIT08R

SIX CHANNEL AC’97 AUDIO CARD

Jumper setting & Connection Rev: 1.0

Jumper setting

Table of Jumpers

LABEL FUNCTION

J1 AVDD Power setting

2.1 AVDD Power ON select

Select the AVDD Power. When you select AVDD power by

+5V, you should close the J1_ (1-2). When you select AVDD

power by +12V to +5V, you should close the J1_ (2-3).

•

J1 : AVDD

J1 DESCRIPTION

1-2

Select AVDD Power

by +5V

2-3

(recommend)

Select AVDD Power

by +12V to +5V

123

■ ● ●

PAGE 1
AC-KIT08R SIX CHANNEL AC’97 AUDIO CARD Jumper setting & Connection Rev: 1.0 Jumper setting LABEL J1 Table of Jumpers FUNCTION AVDD Power setting 2.1 AVDD Power ON select Select the AVDD Power. When you select AVDD power by +5V, you should close the J1_ (1-2). When you select AVDD power by +12V to +5V, you should close the J1_ (2-3).
PAGE 2
Connection This chapter describes how to connect peripherals, switches and indicators to the AC-KIT08R Audio Card. LABEL AC97-1 AUDIO1 CDIN1 AUXIN1 Table of Connectors FUNCTION AC’97 Connector 2 Channel or 6 Channel Audio Output Connector CD in Connector AUX in Connector 3.1 AC’97 Connector • AC97-1: AC’97 Connector PIN NO. DESCRIPTION PIN NO.
PAGE 3
GREEN BLUE PINK 2 CHANNEL LINE OUT LINE IN MIC IN 6 CHANNEL FROUNT OUT SURROUND OUT CENTER_LFE OUT 3.3 CD IN Connector •CDIN1 : 4-pin Header Connector PIN NO. DESCRIPTION 1 CD IN LEFT 2 CD-GND 3 CD-GND 4 CD IN RIGHT 1 2 3 4 ■ ● ● ● 3.4 AUX IN Connector •AUXIN1 : 4-pin Header Connector PIN NO.
