AFOLUX LX Series Flat Panel PC
Page 9
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX
Front Panel
Protection
IP 64 compliant
Safety Meets UL / CE / CCC
EMC Meets CE / FCC class B
Table 1-2: AFOLUX LX Series System Specifications
1.4.3 Motherboard Specifications
The AFOLUX LX series come with an AFLMB-LX800 motherboard. The technical
specifications of the motherboard are listed in
Table 1-3.
Specification AFLMB-LX800
CPU AMD
®
Geode™ LX 800 500Mhz
Southbridge Chipset AMD
®
Geode™ CS5536
Display CRT integrated in AMD
®
Geode™ LX800
24-bit TTL integrated in AMD
®
Geode™ LX800
18-bit LVDS supported by buffer
Memory Supports one 1GB DDR 333/400 200-pin SO-DIMM SDRAM module
Extension One mini PCI slot
BIOS Award BIOS
SSD CF Type II
Super I/O N/A for legacy free
Audio AC'97 Codec Realtek ALC203, AMP 2W
LAN 10/100 Base-T dual RTL8100C
COM 1 x RS-232 serial port
1 x RS-232 or RS-422/485 serial port
IDE One 44-pin IDE connects to two IDE devices
Touch Screen Controller DMC9000
Power Supply DC 12V In
Dimensions 102mm x 186mm
Table 1-3: Motherboard Specifications
