Instruction Manual

IMBA-Q670 ATX Motherboard
Page 93
Î
IO=3BCh;
IRQ=7
Parallel Port I/O port address is 3BCh and the
interrupt address is IRQ7
Î Device Mode [Printer Mode]
Use the Device Mode option to select the mode the parallel port operates in.
Configuration options are listed below.
 Printer Mode Default
 SPP Mode
 EPP-1.9 and SPP Mode
 EPP-1.7 and SPP Mode
 ECP Mode
 ECP and EPP 1.9 Mode
 ECP and EPP 1.7 Mode
5.3.8 H/W Monitor
The H/W Monitor menu (BIOS Menu 13) contains the fan configuration submenus and
displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature :+63 C
SYS Temperature :+33 C
CPU FAN Speed :3006 RPM
SYS FAN Speed :N/A
VCC3V :+3.360 V
V_core :+1.032 V
+1.05V :+1.064 V
VDDR :+1.616 V
VSB3V :+3.424 V
VBAT :+3.200 V
5VSB :+4.968 V
> FAN 1 Configuration
> FAN 2 Configuration
Smart FAN Configuration
---------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: H/W Monitor
