IMBA-Q670 ATX Motherboard
Page 97
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Smart Fan control [Auto by Duty-Cycle]
Target Temp Sensor [CPU Temperature]
Temperature Bound 1 60
Temperature Bound 2 50
Temperature Bound 3 40
Temperature Bound 4 30
Segment 1 Speed (PWM) 100
Segment 1 Speed (PWM) 85
Segment 1 Speed (PWM) 70
Segment 1 Speed (PWM) 60
Segment 1 Speed (PWM) 50
---------------------
ÅÆ
: Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: FAN 2 Configuration
Î CPU Smart Fan control [Auto by Duty-Cycle]
Use the CPU Smart Fan control option to configure the CPU Smart Fan.
Î
Auto by RPM
The fan adjusts its speed using Auto by RPM
settings
Î
Auto by
Duty-Cycle
DEFAULT
The fan adjusts its speed using Auto by
Duty-Cycle settings
Î
Manual by
RPM
The fan spins at the speed set in Manual by RPM
settings
Î
Manual by
Duty-Cycle
The fan spins at the speed set in Manual by Duty
Cycle settings
Î Target Temp. Sensor [CPU Temperature]
Use the Target Temp. Sensor option to set the target CPU temperature.
Î
CPU
Temperature
DEFAULT
Sets the target temperature sensor to the CPU
temperature.
