IMBA-Q670 ATX Motherboard
Page 100
Î
ANSI
The target terminal type is ANSI
Î Bits per second [115200]
Use the Bits per second option to specify the serial port transmission speed. The speed
must match the other side. Long or noisy lines may require lower speeds.
Î
9600
Sets the serial port transmission speed at 9600.
Î
19200
Sets the serial port transmission speed at 19200.
Î
38400
Sets the serial port transmission speed at 38400.
Î
57600
Sets the serial port transmission speed at 57600.
Î
115200 DEFAULT
Sets the serial port transmission speed at 115200.
5.3.10 IEI Feature
Use the IEI Feature menu (BIOS Menu 17) to configure One Key Recovery function.
BIOS SETUP UTILITY
Advanced
iEi Feature
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Auto Recovery Function [Disabled]
ÅÆ
Select Screen
↑ ↓ Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 17: IEI Feature
Î Auto Recovery Function [Disabled]
Use the Auto Recovery Function BIOS option to enable or disable the auto recovery
function of the IEI One Key Recovery.
