5.4.1 Northbridge Configuration
Use the Northbridge Chipset Configuration menu (BIOS Menu 19) to configure the
Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Memory Information
Total Memory 2048 MB (DDR3 1333)
Memory Slot0 2048 MB (DDR3 1333)
Memory Slot1 0 MB (DDR3 1333)
Memory Slot2 0 MB (DDR3 1333)
Memory Slot3 0 MB (DDR3 1333)
Initate Graphic Adapter [PEG/IGD]
IGD Memory [64M]
PCI Express Port [Enabled]
VT-d [Disabled]
Select which graphics
c
ontroller to use as the
primary boot device.
---------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19:Northbridge Chipset Configuration
Î Initiate Graphic Adapter [PEG/IGD]
Use the Initiate Graphic Adapter option to select the graphics controller used as the
primary boot device. Select either an integrated graphics controller (IGD) or a combination
of PCI graphics controller, a PCI express (PEG) controller or an IGD. Configuration
options are listed below:
 IGD
 PCI/IGD
 PCI/PEG
 PEG/IGD D
EFAULT
 PEG/PCI
