Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Auto Power Button Status [OFF]
USB Controller [Enabled]
On-Chip GbE Configuration
GbE Controller [Enabled]
GbE PXE Boot [Disabled]
Wake Event Configuration
Restore AC Power Loss [Power Off]
Resume on PCIE Wake [Enabled]
Resume on PCIE/GbE [Enabled]
Resume on Ring [Enabled]
Resume on PS/2 [Enabled]
Audio Configuration
Azalia HD Audio [Enabled]
Azalia internal HDMI codec [Enabled]
PCI Express Ports Configuration
PCIe LAN Controller [Enabled]
PCIe LAN PXE Boot [Disabled]
PCIe USB3.0 Controller [Enabled]
PCIe x4 Slot1 (PCIe x1) [Enabled]
Enabled/Disabled GbE
Controller. Before
disabling GbE, AMT
function must be
disabled.
---------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: Southbridge Chipset Configuration
Î USB Controller [Enabled]
Use the USB Controller option to enable or disable all USB controller.
Î
Disabled
All of the onboard USB controllers are disabled
Î
Enabled DEFAULT
All of the onboard USB controller are enabled
Î GbE Controller [Enabled]
Use the GbE Controller option to enable or disable the GbE controller. Before disabling
the GbE controller, the AMT function must be disabled.
Î
Disabled
The onboard GbE controller is disabled
Î
Enabled DEFAULT
The onboard GbE controller is enabled
