IMBA-Q670 ATX Motherboard
Page 110
AUTO DEFAULT
CRT
DVI
HDMI
5.4.4 ME Subsystem
Use the ME Subsystem menu (BIOS Menu 22) to configure the Intel® Management
Engine (ME) configuration options.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Intel ME Subsystem Configuration
ME Version 7.0.10.1203
MEBx Mode [Normal]
Unconfigure AMT/ME [Disabled]
MEBx Mode Help
---------------------
ÅÆ
: Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 22: ME Subsystem
Î MEBx Mode [Normal]
Use the MEBx Mode option to configure MEBx Mode options.
Î
Normal DEFAULT
Enables normal mode
Î
Hidden
Ctrl + P
Enables hidden Ctrl+P function
Î
Enter
MEBx
Setup
Enables user to enter MEBx setup
