IMBA-Q670 ATX Motherboard
Page 138
6.8.2 Intel® IT Director Application Installation
Intel® IT Director is an application that helps address key IT security, data protection and
network health concerns of small businesses. To install the Intel® IT Director application,
please do the following.
NOTE:
For Windows XP system, please make sure to install the .net
Framework 3.5 before installing the Intel® IT Director application.
The .net Framework 3.5 setup file is located at \7-iAMT, iTPM Driver &
Utility\Microsoft .NET Framework 3.5 of the driver CD.
Step 1: Access the driver list. (See Section 6.2)
Step 2: Click “iAMT”.
Step 3: Double click the setup file in the Intel_ IT Director folder.
Step 4: Locate the ITDirector_Setup.exe setup file and double click it.
Step 5: The Welcome Screen in
Figure 6-33 appears.
Step 6: Click Next to continue.
