IMBA-Q670 ATX Motherboard
Page 151
partitions. Please take the following table as a reference when calculating the size of the
partition.
OS OS Image after Ghost
Compression Ratio
Windows® 7 7 GB 5 GB 70%
Windows® XPE 776 MB 560 MB 70%
Windows® CE 6.0 36 MB 28 MB 77%
NOTE:
Specialized tools are required to change the partition size if the
operating system is already installed.
B.1.2 Supported Operating System
The recovery CD is compatible with both Microsoft Windows and Linux operating systems
(OS). The supported OS versions are listed below.
Microsoft Windows
o Windows 2000
o Windows XP (Service Pack 2 or 3 required)
o Windows Vista
o Windows 7
o Windows CE 5.0
o Windows CE 6.0
o Windows XP Embedded
o Windows Embedded Standard 7
NOTE:
The auto recovery function (described in Section B.3) and the restore
through LAN function (described in Section
B.6) are not supported in
the Windows CE 5.0/6.0 operating system environment.
