IMBA-Q670 ATX Motherboard
Page 16
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
ATX Power connector 24-pin ATX ATX1
Battery connector 2-pin wafer BT2
Battery holder CR2032 battery holder BAT1
CPU power connector 4-pin Molex CPU12V1
DDR3 DIMM slots DDR3 DIMM slot CHA_DIMM1
CHA_DIMM2
CHB_DIMM1
CHB_DIMM2
Digital I/O 10-pin header DIO1
Fan connector (system 1) 3-pin wafer SYS_FAN1
Fan connector (system 2) 3-pin wafer SYS_FAN2
Fan connector (CPU) 4-pin wafer CPU_FAN1
Front panel audio connector 10-pin header FP_AUDIO1
Front panel connector 14-pin header F_PANEL1
I2C connector 4-pin wafer I2C_1
Keyboard and mouse connector 6-pin wafer KB_MS1
Parallel port connector 26-pin box header LPT1
PCI slots PCI slots PCI1, PCI2,
PCI3, PCI4
PCIe x1 slot PCIe x4 slot PCIEX4_1
PCIe x4 slot PCIe x4 slot PCIEX4_2
PCIe x16 slot PCIe x16 slot PCIEX16_1
SATA 3Gb/s drive connector 14-pin SATA connector SATA34, SATA56
SATA 6Gb/s drive connector 7-pin SATA connector SATA1, SATA2
