IMBA-Q670 ATX Motherboard
Page 59
Figure 4-9: Clear BIOS Jumper Location
4.3.3 Wake-on LAN Jumper
CN Label: WOL_SEL1
CN Type:
3-pin header
CN Location:
See Figure 4-10
CN Pinouts:
See Table 4-4
The Wake-on LAN connector allows the user to enable or disable the Wake-on LAN (WOL)
function.
PIN NO. DESCRIPTION
Short 1-2 Enable Wake-on LAN (Default)
Short 2-3 Disable Wake-on LAN
Table 4-4: Wake-on LAN Connector Pinouts
