IMBA-Q670 ATX Motherboard
Page 81
5.3.4 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode [AHCI Mode]
SATA Port0 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port1 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port2 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port3 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port4 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port5 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.
---------------------
ÅÆ
: Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
Î SATA Mode [AHCI Mode]
Use the SATA Mode option to configure SATA devices as normal IDE devices.
